3DYU

Crystal structure of Snx9PX-BAR (230-595), H32


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.10 Å
  • R-Value Free: 0.403
  • R-Value Work: 0.388
  • R-Value Observed: 0.388

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure and plasticity of endophilin and sorting nexin 9.

Wang, Q.Kaan, H.Y.Hooda, R.N.Goh, S.L.Sondermann, H.

(2008) Structure 16: 1574-1587

  • DOI: https://doi.org/10.1016/j.str.2008.07.016
  • Primary Citation of Related Structures:
    3DYT, 3DYU

  • PubMed Abstract:

    Endophilin and Sorting Nexin 9 (Snx9) play key roles in endocytosis by membrane curvature sensing and remodeling via their Bin/Amphiphysin/Rvs (BAR) domains. BAR and the related F-BAR domains form dimeric, crescent-shaped units that occur N- or C-terminally to other lipid-binding, adaptor, or catalytic modules. In crystal structures, the PX-BAR unit of Snx9 (Snx9(PX-BAR)) adopts an overall compact, moderately curved conformation. SAXS-based solution studies revealed an alternative, more curved state of Snx9(PX-BAR) in which the PX domains are flexibly connected to the BAR domains, providing a model for how Snx9 exhibits lipid-dependent curvature preferences. In contrast, Endophilin appears to be rigid in solution, and the SH3 domains are located at the distal tips of a BAR domain dimer with fixed curvature. We also observed tip-to-tip interactions between the BAR domains in a trigonal crystal form of Snx9(PX-BAR) reminiscent of functionally important interactions described for F-BAR domains.


  • Organizational Affiliation

    Department of Molecular Medicine, College of Veterinary Medicine, Cornell University, Ithaca, NY 14853, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Sorting nexin-9
A, B, C
366Homo sapiensMutation(s): 0
Gene Names: SNX9SH3PX1SH3PXD3A
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y5X1 (Homo sapiens)
Explore Q9Y5X1
Go to UniProtKB:  Q9Y5X1
PHAROS:  Q9Y5X1
GTEx:  ENSG00000130340
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y5X1
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.10 Å
  • R-Value Free: 0.403
  • R-Value Work: 0.388
  • R-Value Observed: 0.388
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 131.765α = 90
b = 131.765β = 90
c = 569.072γ = 120
Software Package:
Software NamePurpose
CNSrefinement
ADSCdata collection
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-09-16
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2023-08-30
    Changes: Data collection, Database references, Refinement description
