3DSH

Crystal structure of dimeric interferon regulatory factor 5 (IRF-5) transactivation domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.204
  • R-Value Observed: 0.206

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Insights into interferon regulatory factor activation from the crystal structure of dimeric IRF5.

Chen, W.Lam, S.S.Srinath, H.Jiang, Z.Correia, J.J.Schiffer, C.A.Fitzgerald, K.A.Lin, K.Royer, W.E.

(2008) Nat Struct Mol Biol 15: 1213-1220

  • DOI: https://doi.org/10.1038/nsmb.1496
  • Primary Citation of Related Structures:
    3DSH

  • PubMed Abstract:

    Interferon regulatory factors (IRFs) are essential in the innate immune response and other physiological processes. Activation of these proteins in the cytoplasm is triggered by phosphorylation of serine and threonine residues in a C-terminal autoinhibitory region, which stimulates dimerization, transport into the nucleus, assembly with the coactivator CBP/p300 and initiation of transcription. The crystal structure of the transactivation domain of pseudophosphorylated human IRF5 strikingly reveals a dimer in which the bulk of intersubunit interactions involve a highly extended C-terminal region. The corresponding region has previously been shown to block CBP/p300 binding to unphosphorylated IRF3. Mutation of key interface residues supports the observed dimer as the physiologically activated state of IRF5 and IRF3. Thus, phosphorylation is likely to activate IRF5 and other family members by triggering conformational rearrangements that switch the C-terminal segment from an autoinihibitory to a dimerization role.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Pharmacology, 364 Plantation Street, Worcester, Massachusetts 01605, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Interferon regulatory factor 5246Homo sapiensMutation(s): 1
Gene Names: IRF5
UniProt & NIH Common Fund Data Resources
Find proteins for Q13568 (Homo sapiens)
Explore Q13568
Go to UniProtKB:  Q13568
PHAROS:  Q13568
GTEx:  ENSG00000128604
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13568
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.204
  • R-Value Observed: 0.206
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.162α = 90
b = 66.162β = 90
c = 156.254γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
SOLVEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-10-07
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Refinement description, Version format compliance
  • Version 1.2: 2021-10-20
    Changes: Database references
  • Version 1.3: 2024-02-21
    Changes: Data collection
