3DCZ | pdb_00003dcz

CRYSTAL STRUCTURE OF A PUTATIVE RNFG SUBUNIT OF ELECTRON TRANSPORT COMPLEX (TM0246) FROM THERMOTOGA MARITIMA AT 1.65 A RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb3DCZ/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Thermotoga maritima
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-06-04 Released: 2008-06-24
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:
  0.205 (Depositor), 0.211 (DCC)
• R-Value Work:
  0.176 (Depositor), 0.181 (DCC)
• R-Value Observed:
  0.177 (Depositor)

Literature

Crystal structure of putative RnfG subunit of electron transport complex (TM0246) from THERMOTOGA MARITIMA at 1.65 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 23.29 kDa
• Atom Count: 1,522
• Modeled Residue Count: 171
• Deposited Residue Count: 207
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
putative RnfG subunit of electron transport complex	A	207	Thermotoga maritima	Mutation(s): 0  Gene Names: TM_0246 EC: 7
UniProt
Find proteins for Q9WY88 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9WY88  Go to UniProtKB:  Q9WY88

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	B [auth A], C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
EDO	E [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
ACT	D [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:  0.205 (Depositor), 0.211 (DCC)
• R-Value Work:  0.176 (Depositor), 0.181 (DCC)
• R-Value Observed: 0.177 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33DCZ

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.125	α = 90
b = 103.827	β = 90
c = 44.035	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-06-24
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2008-06-24
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-30
  Changes: Data collection, Structure summary
