3C1R | pdb_00003c1r

Crystal structure of oxidized GRX1

• PDB DOI: https://doi.org/10.2210/pdb3C1R/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Saccharomyces cerevisiae
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-01-24 Released: 2008-12-09
• Deposition Author(s): Yu, J., Zhou, C.Z.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.205 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.193 (Depositor), 0.191 (DCC)
• R-Value Observed:
  0.193 (Depositor)

Starting Model: experimental

Literature

Glutathionylation-triggered conformational changes of glutaredoxin Grx1 from the yeast Saccharomyces cerevisiae.

Yu, J., Zhang, N.N., Yin, P.D., Cui, P.X., Zhou, C.Z.

(2008) Proteins 72: 1077-1083

• PubMed: 18473363
• DOI: https://doi.org/10.1002/prot.22096
• Primary Citation Related Structures:
  3C1R, 3C1S

---

Organizational Affiliation:
• Hefei National Laboratory for Physical Sciences at Microscale and School of Life Sciences, University of Science and Technology of China, Hefei Anhui 230027, People's Republic of China.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 13.61 kDa
• Atom Count: 999
• Modeled Residue Count: 110
• Deposited Residue Count: 118
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutaredoxin-1	A	118	Saccharomyces cerevisiae	Mutation(s): 0  Gene Names: GRX1 EC: 1.20.4.1 (PDB Primary Data), 2.5.1.18 (UniProt), 1.11.1.9 (UniProt)
UniProt
Find proteins for P25373 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P25373  Go to UniProtKB:  P25373

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MES	B [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C6 H13 N O4 S SXGZJKUKBWWHRA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.205 (Depositor), 0.240 (DCC)
• R-Value Work:  0.193 (Depositor), 0.191 (DCC)
• R-Value Observed: 0.193 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 28.21	α = 90
b = 49.631	β = 94.95
c = 39.701	γ = 90

Software Package:

Software Name	Purpose
MOLREP	phasing
CNS	refinement
MAR345dtb	data collection
AUTOMAR	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-12-09
Deposition Author(s): Yu, J., Zhou, C.Z.

Revision History

• Version 1.0: 2008-12-09
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2023-11-01
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 1.3: 2024-10-16
  Changes: Structure summary
