3BJB | pdb_00003bjb

Crystal structure of a TetR transcriptional regulator from Rhodococcus sp. RHA1

PDB DOI: https://doi.org/10.2210/pdb3BJB/pdb

Classification: TRANSCRIPTION REGULATOR
Organism(s): Rhodococcus jostii RHA1
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2007-12-03 Released: 2007-12-18
Deposition Author(s): Tan, K., Evdokimova, E., Kudritska, M., Savchenko, A., Edwards, A.M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.278 (Depositor), 0.303 (DCC)
R-Value Work:
0.232 (Depositor)
R-Value Observed:
0.234 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

The structure of a TetR transcriptional regulator from Rhodococcus sp. RHA1.

Tan, K., Evdokimova, E., Kudritska, M., Savchenko, A., Edwards, A.M., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 140.12 kDa
Atom Count: 8,429
Modeled Residue Count: 1,073
Deposited Residue Count: 1,242
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable transcriptional regulator, TetR family protein	A, B, C, D, E A, B, C, D, E, F	207	Rhodococcus jostii RHA1	Mutation(s): 0 Gene Names: RHA1_ro05814
UniProt
Find proteins for Q0S4E5 (Rhodococcus jostii (strain RHA1)) Explore Q0S4E5 Go to UniProtKB: Q0S4E5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q0S4E5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain AA [auth F] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain P [auth C] SDF format, chain Q [auth C] SDF format, chain R [auth C] SDF format, chain S [auth C] SDF format, chain T [auth C] SDF format, chain U [auth E] SDF format, chain V [auth E] SDF format, chain W [auth E] SDF format, chain X [auth F] SDF format, chain Y [auth F] SDF format, chain Z [auth F] SDF format, chain O [auth C] MOL2 format, chain AA [auth F] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain P [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain R [auth C] MOL2 format, chain S [auth C] MOL2 format, chain T [auth C] MOL2 format, chain U [auth E] MOL2 format, chain V [auth E] MOL2 format, chain W [auth E] MOL2 format, chain X [auth F] MOL2 format, chain Y [auth F] MOL2 format, chain Z [auth F] MOL2 format, chain O [auth C] mmCIF format, chain AA [auth F] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain P [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain R [auth C] mmCIF format, chain S [auth C] mmCIF format, chain T [auth C] mmCIF format, chain U [auth E] mmCIF format, chain V [auth E] mmCIF format, chain W [auth E] mmCIF format, chain X [auth F] mmCIF format, chain Y [auth F] mmCIF format, chain Z [auth F] mmCIF format, chain O [auth C]	AA [auth F] G [auth A] H [auth A] I [auth A] J [auth A] AA [auth F], G [auth A], H [auth A], I [auth A], J [auth A], K [auth B], L [auth B], M [auth B], N [auth B], O [auth C], P [auth C], Q [auth C], R [auth C], S [auth C], T [auth C], U [auth E], V [auth E], W [auth E], X [auth F], Y [auth F], Z [auth F]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain AA [auth F] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain S [auth C] Focus chain T [auth C] Focus chain U [auth E] Focus chain V [auth E] Focus chain W [auth E] Focus chain X [auth F] Focus chain Y [auth F] Focus chain Z [auth F]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D, E A, B, C, D, E, F	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.278 (Depositor), 0.303 (DCC)
R-Value Work: 0.232 (Depositor)
R-Value Observed: 0.234 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.767	α = 90
b = 93.767	β = 90
c = 314.912	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
SHELXS	phasing
MLPHARE	phasing
DM	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-12-18

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2007-12-18
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.2: 2024-10-16
Changes: Data collection, Database references, Derived calculations, Structure summary
