 3AHA | pdb_00003aha

Crystal structure of the complex between gp41 fragments N36 and C34 mutant N126K/E137Q


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.219 (Depositor), 0.217 (DCC)
  • R-Value Work:
    0.189 (Depositor), 0.187 (DCC)
  • R-Value Observed:
    0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3AHA

This is version 1.4 of the entry. See complete history.

Literature

Characterization of HIV-1 resistance to a fusion inhibitor, N36, derived from the gp41 amino terminal heptad repeat.

Izumi, K., Nakamura, S., Nakano, H., Shimura, K., Sakagami, Y., Oishi, S., Uchiyama, S., Ohkubo, T., Kobayashi, Y., Fujii, N., Matsuoka, M., Kodama, E.N.

(2010) Antiviral Res

  • DOI: https://doi.org/10.1016/j.antiviral.2010.04.011
  • Primary Citation Related Structures:
    3AHA

  • PubMed Abstract:

    A transmembrane glycoprotein of HIV-1, gp41, plays a central role in membrane fusion of HIV-1 and host cells. Peptides derived from the amino- and carboxyl-terminal heptad repeat (N-HR and C-HR, respectively) of gp41 inhibit this fusion. The mechanism of resistance to enfuvirtide, a C-HR-derived peptide, is well defined; however the mechanism of resistance to N-HR-derived peptides remains unclear. We characterized an HIV-1 isolate resistant to the N-HR-derived peptide, N36. This HIV-1 acquired a total of four amino acid substitutions, D36G, N126K and E137Q in gp41, and P183Q in gp120. Among these substitutions, N126K and/or E137Q conferred resistance to not only N36, but also C34, which is the corresponding C-HR-derived peptide fusion inhibitor. We performed crystallographic and biochemical analysis of the 6-helix bundle formed by synthetic gp41-derived peptides containing the N126K/E137Q substitutions. The structure of the 6-helix bundle with N126K/E137Q was identical to that in wild-type HIV-1 except for the presence of a new hydrogen bond. Denaturing experiments revealed that the stability of the 6-helix bundle of N126K/E137Q is greater than in the wild-type. These results suggest that the stabilizing effect of N126K/E137Q provides resistance to N36 and C34.


  • Organizational Affiliation:
    • Laboratory of Virus Control, Institute for Virus Research, Kyoto University, 53 Kawaramachi Shogoin, Sakyo-ku, Kyoto 606-8507, Japan.

Macromolecule Content

  • Total Structure Weight: 25.68 kDa
  • Atom Count: 1,959
  • Modeled Residue Count: 222
  • Deposited Residue Count: 222
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Transmembrane protein gp41
A, C, E
38Human immunodeficiency virus 1Mutation(s): 2
Gene Names: env
UniProt
Find proteins for Q70626 (Human immunodeficiency virus type 1 group M subtype B (isolate LW123))
Explore Q70626
Go to UniProtKB:  Q70626
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ70626
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Transmembrane protein gp41
B, D, F
36Human immunodeficiency virus 1Mutation(s): 4
Gene Names: env
UniProt
Find proteins for Q70626 (Human immunodeficiency virus type 1 group M subtype B (isolate LW123))
Explore Q70626
Go to UniProtKB:  Q70626
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ70626
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.219 (Depositor), 0.217 (DCC)
  • R-Value Work:  0.189 (Depositor), 0.187 (DCC)
  • R-Value Observed: 0.190 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 88.632α = 90
b = 50.479β = 90.88
c = 56.154γ = 90
Software Package:
Software NamePurpose
CrystalCleardata collection
MOLREPphasing
REFMACrefinement
CrystalCleardata reduction
CrystalCleardata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-05-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2021-11-10
    Changes: Database references, Derived calculations
  • Version 1.3: 2023-11-01
    Changes: Data collection, Refinement description
  • Version 1.4: 2024-10-23
    Changes: Structure summary
