34XV | pdb_000034xv

Actinomycetes hydrolase (S148A) bound to 2,4-TDA-DEG

PDB DOI: https://doi.org/10.2210/pdb34XV/pdb

Classification: HYDROLASE
Organism(s): Actinomycetes bacterium
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2026-10-12 Released: 2026-10-21
Deposition Author(s): Bloch, Y., Panneerselvam, S.
Funding Organization(s): H2020 Marie Curie Actions of the European Commission

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.15 Å
R-Value Free:
0.169 (Depositor), 0.166 (DCC)
R-Value Work:
0.143 (Depositor), 0.144 (DCC)
R-Value Observed:
0.144 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 34XV

This is version 1.0 of the entry. See complete history.

Literature

Crystallographic exploration of urethanases.

Bloch, Y., Panneerselvam, S.

To be published.

Macromolecule Content

Total Structure Weight: 68.62 kDa
Atom Count: 5,675
Modeled Residue Count: 601
Deposited Residue Count: 636
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hydrolase GB7	A, B	318	Actinomycetes bacterium	Mutation(s): 0 Gene Names: MCL8208884 EC: 3.5.1.75
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1KUO( Subject of Investigation/LOI) Query on A1KUO Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	2-(2-hydroxyethyloxy)ethyl ~{N}-[3-[2-(2-hydroxyethyloxy)ethoxycarbonylamino]-4-methyl-phenyl]carbamate C₁₇ H₂₆ N₂ O₈ OLYQPHLZVHXEHK-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.15 Å
R-Value Free: 0.169 (Depositor), 0.166 (DCC)
R-Value Work: 0.143 (Depositor), 0.144 (DCC)
R-Value Observed: 0.144 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.546	α = 90
b = 46.408	β = 102.33
c = 92.851	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
autoPROC	data reduction
STARANISO	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-10-21

Deposition Author(s):

Panneerselvam, S.

Funding Organization	Location	Grant Number
H2020 Marie Curie Actions of the European Commission	European Union	945405

Revision History (Full details and data files)

Version 1.0: 2026-10-21
Type: Initial release
