30LF | pdb_000030lf

2.3 A structure of the NBTI B1 with S. aureus DNA gyrase and double-nicked DNA

PDB DOI: https://doi.org/10.2210/pdb30LF/pdb

Classification: ISOMERASE
Organism(s): Staphylococcus aureus subsp. aureus N315, synthetic construct
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2026-05-01 Released: 2026-10-28
Deposition Author(s): Cleenewerk, L., Feng, L., Eltschkner, S., Maxwell, A., Luirink, J.
Funding Organization(s): Netherlands Organisation for Scientific Research (NWO)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.252 (Depositor), 0.252 (DCC)
R-Value Work:
0.213 (Depositor), 0.213 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

To Be Published

Cleenewerk, L., Golda, G., Feng, L., Habjan, E., Speer, A., Lysenko, V., Eltschkner, S., Lawson, D.M., Maxwell, A., Martin, N.I., van Ulsen, P., Luirink, J.

To be published.

Macromolecule Content

Total Structure Weight: 170.21 kDa
Atom Count: 11,604
Modeled Residue Count: 1,380
Deposited Residue Count: 1,424
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA gyrase subunit B,DNA gyrase subunit A	A, B	692	Staphylococcus aureus subsp. aureus N315	Mutation(s): 0 Gene Names: gyrB, SA0005, gyrA, SA0006 EC: 5.6.2.2
UniProt
Find proteins for P66937 (Staphylococcus aureus (strain N315)) Explore P66937 Go to UniProtKB: P66937
Find proteins for Q99XG5 (Staphylococcus aureus (strain N315)) Explore Q99XG5 Go to UniProtKB: Q99XG5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	P66937 Q99XG5
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism
Entity ID: 2
DNA (5'-D(APGPCPCPGPTPAPG)-3')	C [auth E], D [auth G]	8	synthetic construct
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism
Entity ID: 3
DNA (5'-D(PGPTPAPCPCPTPAPCPGPGPCPT)-3')	E [auth F], F [auth H]	12	synthetic construct
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1J72( Subject of Investigation/LOI) Query on A1J72 Download:Ideal Coordinates CCD File SDF format, chain Q [auth H] MOL2 format, chain Q [auth H] mmCIF format, chain Q [auth H]	Q [auth H]	6-[[[1-[[(2~{R})-5,7-bis(fluoranyl)-11-oxidanylidene-1-azatricyclo[6.3.1.0^{4,12}]dodeca-4,6,8(12),9-tetraen-2-yl]methyl]piperidin-4-yl]amino]methyl]-4~{H}-pyrido[3,2-b][1,4]oxazin-3-one C₂₅ H₂₅ F₂ N₅ O₃ RIWRUXORKHOFPU-MRXNPFEDSA-N		Interactions Focus chain Q [auth H] Interactions & Density Focus chain Q [auth H]
A1J73( Subject of Investigation/LOI) Query on A1J73 Download:Ideal Coordinates CCD File SDF format, chain P [auth F] MOL2 format, chain P [auth F] mmCIF format, chain P [auth F]	P [auth F]	6-[[[1-[[(2~{S})-5,7-bis(fluoranyl)-11-oxidanylidene-1-azatricyclo[6.3.1.0^{4,12}]dodeca-4(12),5,7,9-tetraen-2-yl]methyl]piperidin-4-yl]amino]methyl]-4~{H}-pyrido[3,2-b][1,4]oxazin-3-one C₂₅ H₂₅ F₂ N₅ O₃ RIWRUXORKHOFPU-INIZCTEOSA-N		Interactions Focus chain P [auth F] Interactions & Density Focus chain P [auth F]
MES Query on MES Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B]	G [auth A], J [auth B]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Interactions & Density Focus chain G [auth A] Focus chain J [auth B]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain O [auth B] MOL2 format, chain I [auth A] MOL2 format, chain O [auth B] mmCIF format, chain I [auth A] mmCIF format, chain O [auth B]	I [auth A], O [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain I [auth A] Focus chain O [auth B] Interactions & Density Focus chain I [auth A] Focus chain O [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B]	L [auth B], M [auth B], N [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Interactions & Density Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B]
MN Query on MN Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain K [auth B] MOL2 format, chain H [auth A] MOL2 format, chain K [auth B] mmCIF format, chain H [auth A] mmCIF format, chain K [auth B]	H [auth A], K [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain K [auth B] Interactions & Density Focus chain H [auth A] Focus chain K [auth B]
