2I71 | pdb_00002i71

Crystal structure of a Conserved Protein of Unknown Function from Sulfolobus solfataricus P2

PDB DOI: https://doi.org/10.2210/pdb2I71/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Saccharolobus solfataricus P2
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2006-08-30 Released: 2006-10-03
Deposition Author(s): Tan, K., Skarina, T., Onopriyenko, O., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.227 (Depositor), 0.226 (DCC)
R-Value Work:
0.181 (Depositor), 0.180 (DCC)
R-Value Observed:
0.183 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2I71

This is version 1.3 of the entry. See complete history.

Literature

The crystal structure of a Conserved hypothetical protein from Sulfolobus solfataricus P2

Tan, K., Skarina, T., Onopriyenko, O., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 91.74 kDa
Atom Count: 6,785
Modeled Residue Count: 747
Deposited Residue Count: 800
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical protein	A, B	400	Saccharolobus solfataricus P2	Mutation(s): 5 Gene Names: SSO1389 EC: 3.1
UniProt
Find proteins for Q97YD5 (Saccharolobus solfataricus (strain ATCC 35092 / DSM 1617 / JCM 11322 / P2)) Explore Q97YD5 Go to UniProtKB: Q97YD5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q97YD5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.227 (Depositor), 0.226 (DCC)
R-Value Work: 0.181 (Depositor), 0.180 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.849	α = 90
b = 84.918	β = 90
c = 108.513	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-2000	data reduction
HKL-2000	data scaling
HKL-3000	phasing
SHELXE	model building
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2006-10-03

Deposition Author(s):

Onopriyenko, O.

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2006-10-03
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Source and taxonomy, Version format compliance
Version 1.3: 2024-11-13
Changes: Data collection, Database references, Derived calculations, Structure summary
