2ZXX

Crystal structure of Cdt1/geminin complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.235
  • R-Value Observed: 0.237

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural basis for inhibition of the replication licensing factor Cdt1 by geminin

Lee, C.Hong, B.S.Choi, J.M.Kim, Y.Watanabe, S.Ishimi, Y.Enomoto, T.Tada, S.Kim, Y.Cho, Y.

(2004) Nature 430: 913-917

  • DOI: https://doi.org/10.1038/nature02813
  • Primary Citation of Related Structures:
    2ZXX

  • PubMed Abstract:

    To maintain chromosome stability in eukaryotic cells, replication origins must be licensed by loading mini-chromosome maintenance (MCM2-7) complexes once and only once per cell cycle. This licensing control is achieved through the activities of geminin and cyclin-dependent kinases. Geminin binds tightly to Cdt1, an essential component of the replication licensing system, and prevents the inappropriate reinitiation of replication on an already fired origin. The inhibitory effect of geminin is thought to prevent the interaction between Cdt1 and the MCM helicase. Here we describe the crystal structure of the mouse geminin-Cdt1 complex using tGeminin (residues 79-157, truncated geminin) and tCdt1 (residues 172-368, truncated Cdt1). The amino-terminal region of a coiled-coil dimer of tGeminin interacts with both N-terminal and carboxy-terminal parts of tCdt1. The primary interface relies on the steric complementarity between the tGeminin dimer and the hydrophobic face of the two short N-terminal helices of tCdt1 and, in particular, Pro 181, Ala 182, Tyr 183, Phe 186 and Leu 189. The crystal structure, in conjunction with our biochemical data, indicates that the N-terminal region of tGeminin might be required to anchor tCdt1, and the C-terminal region of tGeminin prevents access of the MCM complex to tCdt1 through steric hindrance.


  • Organizational Affiliation

    National Creative Research Center for Structural Biology and Department of Life Science, Pohang University of Science and Technology, Hyo-ja dong, San31, Pohang, KyungBook, South Korea.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Geminin
A, B, D, E
79Mus musculusMutation(s): 0
Gene Names: gemininGmnn
UniProt & NIH Common Fund Data Resources
Find proteins for O88513 (Mus musculus)
Explore O88513
Go to UniProtKB:  O88513
IMPC:  MGI:1927344
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO88513
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication factor Cdt1
C, F
197Mus musculusMutation(s): 0
Gene Names: Cdt1
UniProt
Find proteins for Q8R4E9 (Mus musculus)
Explore Q8R4E9
Go to UniProtKB:  Q8R4E9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8R4E9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, D, E
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.235
  • R-Value Observed: 0.237
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 113.769α = 90
b = 94.334β = 103.66
c = 115.572γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-02-17
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2024-11-20
    Changes: Data collection, Database references, Derived calculations, Structure summary
