2ZS1

Structural Basis for the Heterotropic and Homotropic Interactions of Invertebrate Giant Hemoglobin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.207
  • R-Value Work: 0.180
  • R-Value Observed: 0.180

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structural Basis for the Heterotropic and Homotropic Interactions of Invertebrate Giant Hemoglobin

Numoto, N.Nakagawa, T.Kita, A.Sasayama, Y.Fukumori, Y.Miki, K.

(2008) Biochemistry 47: 11231-11238

  • DOI: https://doi.org/10.1021/bi8012609
  • Primary Citation of Related Structures:
    2ZS0, 2ZS1

  • PubMed Abstract:

    The oxygen binding properties of extracellular giant hemoglobins (Hbs) in some annelids exhibit features significantly different from those of vertebrate tetrameric Hbs. Annelid giant Hbs show cooperative oxygen binding properties in the presence of inorganic cations, while the cooperativities of vertebrate Hbs are enhanced by small organic anions or chloride ions. To elucidate the structural basis for the cation-mediated cooperative mechanisms of these giant Hbs, we determined the crystal structures of Ca2+- and Mg2+-bound Hbs from Oligobrachia mashikoi at 1.6 and 1.7 A resolution, respectively. Both of the metal-bound structures were determined in the oxygenated state. Four Ca2+-binding sites and one Mg2+-binding site were identified in each tetramer subassembly. These cations are considered to stabilize the oxygenated form and increase affinity and cooperativity for oxygen binding, as almost all of the Ca2+ and Mg2+ cations were bound at the interface regions, forming either direct or hydrogen bond-mediated interactions with the neighboring subunits. A comparison of the structures of the oxygenated form and the partially unliganded form provides structural insight into proton-coupled cooperativity (Bohr effect) and ligand-induced transitions. Two histidine residues are assumed to be primarily associated with the Bohr effect. With regard to the ligand-induced cooperativity, a novel quaternary rotation mechanism is proposed to exist at the interface region of the dimer subassembly. Interactions among conserved residues Arg E10, His F3, Gln F7, and Val E11, together with the bending motion of the heme molecules, appear to be essential for quaternary rearrangement.


  • Organizational Affiliation

    Department of Chemistry, Graduate School of Science, Kyoto UniVersity, Sakyo-ku, Kyoto 606-8502, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Extracellular giant hemoglobin major globin subunit A1140Oligobrachia mashikoiMutation(s): 0
UniProt
Find proteins for Q7M419 (Oligobrachia mashikoi)
Explore Q7M419
Go to UniProtKB:  Q7M419
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7M419
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Extracellular giant hemoglobin major globin subunit A2142Oligobrachia mashikoiMutation(s): 0
UniProt
Find proteins for Q7M413 (Oligobrachia mashikoi)
Explore Q7M413
Go to UniProtKB:  Q7M413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7M413
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Extracellular giant hemoglobin major globin subunit B2147Oligobrachia mashikoiMutation(s): 0
UniProt
Find proteins for Q7M418 (Oligobrachia mashikoi)
Explore Q7M418
Go to UniProtKB:  Q7M418
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7M418
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Extracellular giant hemoglobin major globin subunit B1145Oligobrachia mashikoiMutation(s): 10
UniProt
Find proteins for Q5KSB7 (Oligobrachia mashikoi)
Explore Q5KSB7
Go to UniProtKB:  Q5KSB7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5KSB7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEM
Query on HEM

Download Ideal Coordinates CCD File
E [auth A],
L [auth B],
O [auth C],
Q [auth D]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
G [auth A]
H [auth A]
I [auth A]
J [auth A]
S [auth D]
G [auth A],
H [auth A],
I [auth A],
J [auth A],
S [auth D],
T [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
K [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
OXY
Query on OXY

Download Ideal Coordinates CCD File
F [auth A],
M [auth B],
P [auth C],
R [auth D]
OXYGEN MOLECULE
O2
MYMOFIZGZYHOMD-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
N [auth B]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.207
  • R-Value Work: 0.180
  • R-Value Observed: 0.180
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 111.302α = 90
b = 111.302β = 90
c = 274.93γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
CNSrefinement
PDB_EXTRACTdata extraction
BSSdata collection
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-10-21
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.2: 2017-10-11
    Changes: Refinement description
  • Version 1.3: 2023-11-01
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.4: 2024-10-16
    Changes: Structure summary
