2YNI | pdb_00002yni

HIV-1 Reverse Transcriptase in complex with inhibitor GSK952

PDB DOI: https://doi.org/10.2210/pdb2YNI/pdb

Classification: HYDROLASE
Organism(s): HIV-1 M:B_HXB2R
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2012-10-15 Released: 2013-01-09
Deposition Author(s): Chong, P., Sebahar, P., Youngman, M., Garrido, D., Zhang, H., Stewart, E.L., Nolte, R.T., Wang, L., Ferris, R.G., Edelstein, M., Weaver, K., Mathis, A., Peat, A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.49 Å
R-Value Free:
0.254 (Depositor), 0.252 (DCC)
R-Value Work:
0.202 (Depositor), 0.204 (DCC)
R-Value Observed:
0.204 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Rational Design of Potent Non-Nucleoside Inhibitors of HIV-1 Reverse Transcriptase.

Chong, P., Sebahar, P., Youngman, M., Garrido, D., Zhang, H., Stewart, E.L., Nolte, R.T., Wang, L., Ferris, R.G., Edelstein, M., Weaver, K., Mathis, A., Peat, A.

(2012) J Med Chem 55: 10601

PubMed: 23137340 Search on PubMed
DOI: https://doi.org/10.1021/jm301294g
Primary Citation Related Structures:
2YNF, 2YNG, 2YNH, 2YNI

PubMed Abstract:
A new series of non-nucleoside reverse transcriptase inhibitors based on an imidazole-amide biarylether scaffold has been identified and shown to possess potent antiviral activity against HIV-1, including the NNRTI-resistant Y188L mutated virus. X-ray crystallography of inhibitors bound to reverse transcriptase, including a structure of the Y188L RT protein, was used extensively to help identify and optimize the key hydrogen-bonding motif. This led directly to the design of compound 43 that exhibits remarkable antiviral activity (EC50<1 nM) against a wide range of NNRTI-resistant viruses and a favorable pharmacokinetic profile across multiple species.

Organizational Affiliation

GlaxoSmithKline Research & Development, 5 Moore Drive, Research Triangle Park, North Carolina 27709, United States.

Macromolecule Content

Total Structure Weight: 117.75 kDa
Atom Count: 8,268
Modeled Residue Count: 964
Deposited Residue Count: 1,010
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
REVERSE TRANSCRIPTASE/RIBONUCLEASE H	A	563	HIV-1 M:B_HXB2R	Mutation(s): 0 EC: 2.7.7.49 (PDB Primary Data), 2.7.7.7 (PDB Primary Data), 3.1.26.13 (PDB Primary Data), 3.1.13.2 (PDB Primary Data)
UniProt
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B (isolate HXB2)) Explore P04585 Go to UniProtKB: P04585
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P04585
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
P51 RT	B	447	HIV-1 M:B_HXB2R	Mutation(s): 0
UniProt
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B (isolate HXB2)) Explore P04585 Go to UniProtKB: P04585
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P04585
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CXD Query on CXD Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	4-chloranyl-N-[[4-chloranyl-3-(3-chloranyl-5-cyano-phenoxy)-2-fluoranyl-phenyl]methyl]-1H-imidazole-5-carboxamide C₁₈ H₁₀ Cl₃ F N₄ O₂ FCSGFPSBYUHMIF-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
TAR Query on TAR Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	D(-)-TARTARIC ACID C₄ H₆ O₆ FEWJPZIEWOKRBE-LWMBPPNESA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.49 Å
R-Value Free: 0.254 (Depositor), 0.252 (DCC)
R-Value Work: 0.202 (Depositor), 0.204 (DCC)
R-Value Observed: 0.204 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 118.497	α = 90
b = 154.577	β = 90
c = 156.406	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-01-09

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-01-09
Type: Initial release
Version 1.1: 2013-12-18
Changes: Structure summary
Version 1.2: 2023-12-20
Changes: Data collection, Database references, Derived calculations, Other, Refinement description
