2XUC

Natural product-guided discovery of a fungal chitinase inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.233
  • R-Value Observed: 0.233

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Natural Product-Guided Discovery of a Fungal Chitinase Inhibitor.

Rush, C.L.Schuttelkopf, A.W.Hurtado-Guerrero, R.Blair, D.E.Ibrahim, A.F.M.Desvergnes, S.Eggleston, I.M.van Aalten, D.M.F.

(2010) Chem Biol 17: 1275

  • DOI: https://doi.org/10.1016/j.chembiol.2010.07.018
  • Primary Citation of Related Structures:
    2XUC, 2XVN, 2XVP

  • PubMed Abstract:

    Natural products are often large, synthetically intractable molecules, yet frequently offer surprising inroads into previously unexplored chemical space for enzyme inhibitors. Argifin is a cyclic pentapeptide that was originally isolated as a fungal natural product. It competitively inhibits family 18 chitinases by mimicking the chitooligosaccharide substrate of these enzymes. Interestingly, argifin is a nanomolar inhibitor of the bacterial-type subfamily of fungal chitinases that possess an extensive chitin-binding groove, but does not inhibit the much smaller, plant-type enzymes from the same family that are involved in fungal cell division and are thought to be potential drug targets. Here we show that a small, highly efficient, argifin-derived, nine-atom fragment is a micromolar inhibitor of the plant-type chitinase ChiA1 from the opportunistic pathogen Aspergillus fumigatus. Evaluation of the binding mode with the first crystal structure of an A. fumigatus plant-type chitinase reveals that the compound binds the catalytic machinery in the same manner as observed for argifin with the bacterial-type chitinases. The structure of the complex was used to guide synthesis of derivatives to explore a pocket near the catalytic machinery. This work provides synthetically tractable plant-type family 18 chitinase inhibitors from the repurposing of a natural product.


  • Organizational Affiliation

    Division of Molecular Microbiology, College of Life Sciences, University of Dundee, Dundee DD15EH, Scotland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CHITINASE
A, B, C
310Aspergillus fumigatusMutation(s): 0
EC: 3.2.1.14
UniProt
Find proteins for Q873Y0 (Aspergillus fumigatus)
Explore Q873Y0
Go to UniProtKB:  Q873Y0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ873Y0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
XRG
Query on XRG

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
H [auth B],
I [auth B],
M [auth C]
1-methyl-3-(N-methylcarbamimidoyl)urea
C4 H10 N4 O
KGCIDHJBLPVUNN-UHFFFAOYSA-N
PO4
Query on PO4

Download Ideal Coordinates CCD File
F [auth A],
J [auth B],
K [auth B],
N [auth C]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
CL
Query on CL

Download Ideal Coordinates CCD File
G [auth A],
L [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Binding Affinity Annotations
IDSourceBinding Affinity
XRG PDBBind:  2XUC IC50: 7.90e+4 (nM) from 1 assay(s)
BindingDB:  2XUC IC50: 7.90e+4 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.233
  • R-Value Observed: 0.233
  • Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 100.039α = 90
b = 100.039β = 90
c = 111.156γ = 120
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2010-10-27
    Type: Initial release
  • Version 1.1: 2011-05-26
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2018-05-16
    Changes: Data collection, Database references, Structure summary
  • Version 1.4: 2019-01-23
    Changes: Advisory, Data collection, Derived calculations
  • Version 1.5: 2024-11-13
    Changes: Data collection, Database references, Derived calculations, Other, Structure summary
