2RKK | pdb_00002rkk

Crystal Structure of S.cerevisiae Vta1 N-terminal domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.260 (Depositor), 0.261 (DCC)
  • R-Value Work:
    0.215 (Depositor), 0.216 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 2RKK

This is version 1.3 of the entry. See complete history

Literature

Structural basis of vta1 function in the multivesicular body sorting pathway.

Xiao, J.Xia, H.Zhou, J.Azmi, I.F.Davies, B.A.Katzmann, D.J.Xu, Z.

(2008) Dev Cell 14: 37-49

  • DOI: https://doi.org/10.1016/j.devcel.2007.10.013
  • Primary Citation Related Structures:
    2RKK, 2RKL

  • PubMed Abstract:

    The MVB pathway plays essential roles in several eukaryotic cellular processes. Proper function of the MVB pathway requires reversible membrane association of the ESCRTs, a process catalyzed by Vps4 ATPase. Vta1 regulates the Vps4 activity, but its mechanism of action was poorly understood. We report the high-resolution crystal structures of the Did2- and Vps60-binding N-terminal domain and the Vps4-binding C-terminal domain of S. cerevisiae Vta1. The C-terminal domain also mediates Vta1 dimerization and both subunits are required for its function as a Vps4 regulator. Emerging from our analysis is a mechanism of regulation by Vta1 in which the C-terminal domain stabilizes the ATP-dependent double ring assembly of Vps4. In addition, the MIT motif-containing N-terminal domain, projected by a long disordered linker, allows contact between the Vps4 disassembly machinery and the accessory ESCRT-III proteins. This provides an additional level of regulation and coordination for ESCRT-III assembly and disassembly.


  • Organizational Affiliation
    • Life Sciences Institute and Department of Biological Chemistry, Medical School, University of Michigan, Ann Arbor, MI 48109, USA.

Macromolecule Content

  • Total Structure Weight: 38.3 kDa
  • Atom Count: 2,529
  • Modeled Residue Count: 314
  • Deposited Residue Count: 336
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Vacuolar protein sorting-associated protein VTA1
A, B
168Saccharomyces cerevisiaeMutation(s): 0
Gene Names: VTA1
UniProt
Find proteins for Q06263 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q06263
Go to UniProtKB:  Q06263
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ06263
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.260 (Depositor), 0.261 (DCC)
  • R-Value Work:  0.215 (Depositor), 0.216 (DCC)
Space Group: I 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 126.169α = 90
b = 126.169β = 90
c = 70.252γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SHARPphasing
DMphasing
CNSrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-01-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-10-25
    Changes: Refinement description
  • Version 1.3: 2024-02-21
    Changes: Data collection, Database references
