2PNY | pdb_00002pny

Structure of Human Isopentenyl-diphosphate Delta-isomerase 2

• PDB DOI: https://doi.org/10.2210/pdb2PNY/pdb

• Classification: ISOMERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2007-04-25 Released: 2007-05-29
• Deposition Author(s): Walker, J.R., Davis, T., Butler-Cole, C., Weigelt, J., Sundstrom, M., Arrowsmith, C.H., Edwards, A.M., Bochkarev, A., Dhe-Paganon, S., Structural Genomics Consortium (SGC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.81 Å
• R-Value Free:
  0.182 (Depositor), 0.186 (DCC)
• R-Value Work:
  0.148 (Depositor), 0.153 (DCC)
• R-Value Observed:
  0.149 (Depositor)

Starting Model: experimental

Literature

Structure of the human Isopentenyl-diphosphate Delta-isomerase 2.

Walker, J.R., Davis, T., Butler-Cole, C., Weigelt, J., Sundstrom, M., Arrowsmith, C.H., Edwards, A.M., Bochkarev, A., Dhe-Paganon, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 29.37 kDa
• Atom Count: 2,230
• Modeled Residue Count: 233
• Deposited Residue Count: 246
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isopentenyl-diphosphate Delta-isomerase 2	A	246	Homo sapiens	Mutation(s): 0  Gene Names: IDI2 EC: 5.3.3.2
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BXS1 (Homo sapiens) Explore Q9BXS1  Go to UniProtKB:  Q9BXS1
PHAROS:  Q9BXS1 GTEx:  ENSG00000148377

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
POP	D [auth A]	PYROPHOSPHATE 2- H2 O7 P2 XPPKVPWEQAFLFU-UHFFFAOYSA-L
GOL	E [auth A], F [auth A], G [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
MN	C [auth A]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N
CA	B [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.81 Å
• R-Value Free:  0.182 (Depositor), 0.186 (DCC)
• R-Value Work:  0.148 (Depositor), 0.153 (DCC)
• R-Value Observed: 0.149 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.897	α = 90
b = 52.815	β = 90
c = 96.391	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data collection
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-05-29
Deposition Author(s): Walker, J.R., Davis, T., Butler-Cole, C., Weigelt, J., Sundstrom, M., Arrowsmith, C.H., Edwards, A.M., Bochkarev, A., Dhe-Paganon, S., Structural Genomics Consortium (SGC)

Revision History

• Version 1.0: 2007-05-29
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Non-polymer description, Version format compliance
• Version 1.3: 2023-08-30
  Changes: Data collection, Database references, Derived calculations, Refinement description
