2ODL | pdb_00002odl

Crystal structure of the HMW1 secretion domain from Haemophilus influenzae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.92 Å
  • R-Value Free:
    0.217 (Depositor), 0.216 (DCC)
  • R-Value Work:
    0.174 (Depositor), 0.175 (DCC)
  • R-Value Observed:
    0.176 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2ODL

This is version 1.3 of the entry. See complete history

Literature

The structure of the Haemophilus influenzae HMW1 pro-piece reveals a structural domain essential for bacterial two-partner secretion.

Yeo, H.J.Yokoyama, T.Walkiewicz, K.Kim, Y.Grass, S.Geme, J.W.

(2007) J Biological Chem 282: 31076-31084

  • DOI: https://doi.org/10.1074/jbc.M705750200
  • Primary Citation Related Structures:
    2ODL

  • PubMed Abstract:

    In pathogenic Gram-negative bacteria, many virulence factors are secreted via the two-partner secretion pathway, which consists of an exoprotein called TpsA and a cognate outer membrane translocator called TpsB. The HMW1 and HMW2 adhesins are major virulence factors in nontypeable Haemophilus influenzae and are prototype two-partner secretion pathway exoproteins. A key step in the delivery of HMW1 and HMW2 to the bacterial surface involves targeting to the HMW1B and HMW2B outer membrane translocators by an N-terminal region called the secretion domain. Here we present the crystal structure at 1.92 A of the HMW1 pro-piece (HMW1-PP), a region that contains the HMW1 secretion domain and is cleaved and released during HMW1 secretion. Structural analysis of HMW1-PP revealed a right-handed beta-helix fold containing 12 complete parallel coils and one large extra-helical domain. Comparison of HMW1-PP and the Bordetella pertussis FHA secretion domain (Fha30) reveals limited amino acid homology but shared structural features, suggesting that diverse TpsA proteins have a common structural domain required for targeting to cognate TpsB proteins. Further comparison of HMW1-PP and Fha30 structures may provide insights into the keen specificity of TpsA-TpsB interactions.


  • Organizational Affiliation
    • Department of Biology and Biochemistry, University of Houston, Houston, Texas 77204, USA. hyeo@uh.edu

Macromolecule Content

  • Total Structure Weight: 39.36 kDa
  • Atom Count: 2,927
  • Modeled Residue Count: 372
  • Deposited Residue Count: 373
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Adhesin373Haemophilus influenzaeMutation(s): 4
Gene Names: hmw1A
UniProt
Find proteins for Q48031 (Haemophilus influenzae)
Explore Q48031
Go to UniProtKB:  Q48031
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ48031
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.92 Å
  • R-Value Free:  0.217 (Depositor), 0.216 (DCC)
  • R-Value Work:  0.174 (Depositor), 0.175 (DCC)
  • R-Value Observed: 0.176 (Depositor)
Space Group: I 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 121.438α = 90
b = 121.438β = 90
c = 50.582γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data collection
HKL-2000data reduction
SCALEPACKdata scaling
SHARPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-08-21
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2023-12-27
    Changes: Data collection, Database references, Derived calculations
  • Version 1.3: 2024-11-20
    Changes: Structure summary
