2HXI | pdb_00002hxi

Structural Genomics, the crystal structure of a putative transcriptional regulator from Streptomyces coelicolor A3(2)

PDB DOI: https://doi.org/10.2210/pdb2HXI/pdb

Classification: TRANSCRIPTION
Organism(s): Streptomyces coelicolor A3(2)
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2006-08-03 Released: 2006-09-05
Deposition Author(s): Tan, K., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.232 (Depositor), 0.194 (DCC)
R-Value Work:
0.187 (Depositor), 0.188 (DCC)
R-Value Observed:
0.190 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2HXI

This is version 1.3 of the entry. See complete history.

Literature

The crystal structure of a putative transcriptional regulator TetR from Streptomyces coelicolor A3(2)

Tan, K., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 53.07 kDa
Atom Count: 3,483
Modeled Residue Count: 395
Deposited Residue Count: 482
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative transcriptional regulator	A, B	241	Streptomyces coelicolor A3(2)	Mutation(s): 3
UniProt
Find proteins for O87854 (Streptomyces coelicolor (strain ATCC BAA-471 / A3(2) / M145)) Explore O87854 Go to UniProtKB: O87854
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O87854
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.232 (Depositor), 0.194 (DCC)
R-Value Work: 0.187 (Depositor), 0.188 (DCC)
R-Value Observed: 0.190 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 44.338	α = 90
b = 94.868	β = 95.61
c = 51.835	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-2000	data reduction
HKL-2000	data scaling
HKLSBC	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2006-09-05

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2006-09-05
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Source and taxonomy, Version format compliance
Version 1.3: 2024-10-30
Changes: Data collection, Database references, Derived calculations, Structure summary
