2HIS | pdb_00002his

CELLULOMONAS FIMI XYLANASE/CELLULASE DOUBLE MUTANT E127A/H205N WITH COVALENT CELLOBIOSE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.84 Å
  • R-Value Free:
    0.280 (Depositor)
  • R-Value Work:
    0.220 (Depositor)
  • R-Value Observed:
    0.220 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2HIS

This is version 2.3 of the entry. See complete history

Literature

Insights into transition state stabilization of the beta-1,4-glycosidase Cex by covalent intermediate accumulation in active site mutants.

Notenboom, V.Birsan, C.Nitz, M.Rose, D.R.Warren, R.A.Withers, S.G.

(1998) Nat Struct Biol 5: 812-818

  • DOI: https://doi.org/10.1038/1852
  • Primary Citation Related Structures:
    2HIS

  • PubMed Abstract:

    The catalytic mechanism of 'retaining' beta-glycosidases has been the subject of considerable interest and debate for many years. The visualization of a covalent glycosyl enzyme intermediate by X-ray crystallography was first accomplished with a saccharide substrate substituted with fluorine at its 2-position. The structure implicated major roles for residue His 205 and for the 2-hydroxyl position of the proximal saccharide in binding and catalysis. Here we have studied the kinetic behavior of various His 205 mutants. One of these mutants, a double mutant H205N/E127A, has been used to stabilize a covalent glycosyl-enzyme intermediate involving an unsubstituted sugar, permitting crystallographic analysis of the interactions between its 2-hydroxyl group and the enzyme.


  • Organizational Affiliation
    • Protein Engineering Network of Centres of Excellence, Ontario Cancer Institute and Department of Medical Biophysics, University of Toronto, Canada.

Macromolecule Content

  • Total Structure Weight: 34.31 kDa
  • Atom Count: 2,543
  • Modeled Residue Count: 312
  • Deposited Residue Count: 312
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
CELLULOMONAS FIMI FAMILY 10 BETA-1,4-GLYCANASE312Cellulomonas fimiMutation(s): 2
EC: 3.2.1.91 (PDB Primary Data), 3.2.1.8 (UniProt)
UniProt
Find proteins for P07986 (Cellulomonas fimi)
Explore P07986
Go to UniProtKB:  P07986
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07986
Glycosylation
Glycosylation Sites: 1
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-glucopyranose-(1-4)-alpha-D-glucopyranose
B
2N/A
Glycosylation Resources
GlyTouCan: G86802XL
GlyCosmos: G86802XL

Biologically Interesting Molecules (External Reference)

1 Unique
Entity ID: 2
IDChains NameType/Class2D Diagram3D Interactions
PRD_900023
Query on PRD_900023
B
alpha-cellobioseOligosaccharide / Metabolism

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.84 Å
  • R-Value Free:  0.280 (Depositor)
  • R-Value Work:  0.220 (Depositor)
  • R-Value Observed: 0.220 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 88.411α = 90
b = 88.411β = 90
c = 80.675γ = 90
Software Package:
Software NamePurpose
SDMWdata collection
X-PLORmodel building
X-PLORrefinement
SDMSdata reduction
XENGENdata reduction
NIELSENdata reduction
XUONG)data reduction
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1998-10-14
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Other, Structure summary
  • Version 2.1: 2021-11-03
    Changes: Database references, Structure summary
  • Version 2.2: 2023-08-09
    Changes: Refinement description
  • Version 2.3: 2024-10-16
    Changes: Data collection, Structure summary
