2GWN | pdb_00002gwn

The structure of putative dihydroorotase from Porphyromonas gingivalis.

PDB DOI: https://doi.org/10.2210/pdb2GWN/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Porphyromonas gingivalis W83
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2006-05-04 Released: 2006-06-06
Deposition Author(s): Cuff, M.E., Borovilos, M., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.194 (Depositor), 0.193 (DCC)
R-Value Work:
0.149 (Depositor), 0.148 (DCC)
R-Value Observed:
0.151 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

The structure of putative dihydroorotase from Porphyromonas gingivalis.

Cuff, M.E., Borovilos, M., Moy, S., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 51.99 kDa
Atom Count: 4,214
Modeled Residue Count: 451
Deposited Residue Count: 452
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
dihydroorotase	A	452	Porphyromonas gingivalis W83	Mutation(s): 8 Gene Names: pyrC
UniProt
Find proteins for Q7MVW1 (Porphyromonas gingivalis (strain ATCC BAA-308 / W83)) Explore Q7MVW1 Go to UniProtKB: Q7MVW1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7MVW1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CAC Query on CAC Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A]	CACODYLATE ION C₂ H₆ As O₂ OGGXGZAMXPVRFZ-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A]	G [auth A], H [auth A], I [auth A], J [auth A], K [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain O [auth A] SDF format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A]	N [auth A], O [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain N [auth A] Focus chain O [auth A] Interactions & Density Focus chain N [auth A] Focus chain O [auth A]
BME Query on BME Download:Ideal Coordinates CCD File SDF format, chain M [auth A] SDF format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A]	L [auth A], M [auth A]	BETA-MERCAPTOETHANOL C₂ H₆ O S DGVVWUTYPXICAM-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain L [auth A] Focus chain M [auth A]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]

Modified Residues 2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
KCX Query on KCX	A	L-PEPTIDE LINKING	C₇ H₁₄ N₂ O₄		LYS
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.194 (Depositor), 0.193 (DCC)
R-Value Work: 0.149 (Depositor), 0.148 (DCC)
R-Value Observed: 0.151 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.459	α = 90
b = 86.873	β = 90
c = 114.581	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-2000	data scaling
HKL-3000	phasing
SHELX	phasing
CCP4	phasing
MLPHARE	phasing
DM	phasing
SOLVE	phasing
RESOLVE	phasing
O	model building
ARP/wARP	model building
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2006-06-06

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2006-06-06
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.3: 2025-03-26
Changes: Data collection, Database references, Derived calculations, Structure summary
