2GIY | pdb_00002giy

Crystal Structure of the C-terminal domain of the HSV-1 gE ectodomain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free:
    0.220 (Depositor), 0.220 (DCC)
  • R-Value Work:
    0.198 (Depositor), 0.197 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 2GIY

This is version 1.4 of the entry. See complete history

Literature

Crystal Structure of the HSV-1 Fc Receptor Bound to Fc Reveals a Mechanism for Antibody Bipolar Bridging.

Sprague, E.R.Wang, C.Baker, D.Bjorkman, P.J.

(2006) PLoS Biol 4: 1-12

  • DOI: https://doi.org/10.1371/journal.pbio.0040148
  • Primary Citation Related Structures:
    2GIY, 2GJ7

  • PubMed Abstract:

    Herpes simplex virus type-1 expresses a heterodimeric Fc receptor, gE-gI, on the surfaces of virions and infected cells that binds the Fc region of host immunoglobulin G and is implicated in the cell-to-cell spread of virus. gE-gI binds immunoglobulin G at the basic pH of the cell surface and releases it at the acidic pH of lysosomes, consistent with a role in facilitating the degradation of antiviral antibodies. Here we identify the C-terminal domain of the gE ectodomain (CgE) as the minimal Fc-binding domain and present a 1.78-angstroms CgE structure. A 5-angstroms gE-gI/Fc crystal structure, which was independently verified by a theoretical prediction method, reveals that CgE binds Fc at the C(H)2-C(H)3 interface, the binding site for several mammalian and bacterial Fc-binding proteins. The structure identifies interface histidines that may confer pH-dependent binding and regions of CgE implicated in cell-to-cell spread of virus. The ternary organization of the gE-gI/Fc complex is compatible with antibody bipolar bridging, which can interfere with the antiviral immune response.


  • Organizational Affiliation
    • Division of Biology, California Institute of Technology, Pasadena, California, USA.

Macromolecule Content

  • Total Structure Weight: 42.29 kDa
  • Atom Count: 3,014
  • Modeled Residue Count: 357
  • Deposited Residue Count: 382
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Glycoprotein E
A, B
191Human alphaherpesvirus 1 strain KOSMutation(s): 0
Gene Names: GEUS8
UniProt
Find proteins for P04488 (Human herpesvirus 1 (strain 17))
Go to UniProtKB:  P04488
Find proteins for Q703E9 (Human herpesvirus 1)
Explore Q703E9
Go to UniProtKB:  Q703E9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ703E9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free:  0.220 (Depositor), 0.220 (DCC)
  • R-Value Work:  0.198 (Depositor), 0.197 (DCC)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.681α = 90
b = 91.242β = 117.64
c = 47.409γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SOLVEphasing
RESOLVEphasing
CNSrefinement
PDB_EXTRACTdata extraction
Blu-Icedata collection

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-05-30
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Source and taxonomy, Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2024-11-06
    Changes: Data collection, Database references, Structure summary
