2EKD | pdb_00002ekd

Structural study of Project ID PH0250 from Pyrococcus horikoshii OT3

• PDB DOI: https://doi.org/10.2210/pdb2EKD/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Pyrococcus horikoshii OT3
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2007-03-22 Released: 2007-09-25
• Deposition Author(s): Asada, Y., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.225 (Depositor), 0.224 (DCC)
• R-Value Work:
  0.188 (Depositor), 0.188 (DCC)
• R-Value Observed:
  0.190 (Depositor)

Literature

Structural study of Project ID PH0250 from Pyrococcus horikoshii OT3

Asada, Y., Kunishima, N.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C6  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Dihedral - D6  (Explore in 3D)
Global Stoichiometry: Homo 12-mer - A12

Biological assembly 2 generated by PISA,PQS (software)

Macromolecule Content

• Total Structure Weight: 143.19 kDa
• Atom Count: 10,430
• Modeled Residue Count: 1,219
• Deposited Residue Count: 1,242
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical protein PH0250	A, B, C, D, E, F	207	Pyrococcus horikoshii OT3	Mutation(s): 5
UniProt
Find proteins for O57988 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3)) Explore O57988  Go to UniProtKB:  O57988

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CL	G [auth C], H [auth D], I [auth F]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D, E, F	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.225 (Depositor), 0.224 (DCC)
• R-Value Work:  0.188 (Depositor), 0.188 (DCC)
• R-Value Observed: 0.190 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.471	α = 90
b = 158.026	β = 90
c = 163.347	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
SOLVE	phasing
CNS	refinement
HKL-2000	data reduction
SCALEPACK	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-09-25
Deposition Author(s): Asada, Y., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2007-09-25
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Derived calculations, Source and taxonomy, Version format compliance
• Version 1.2: 2024-11-20
  Changes: Data collection, Database references, Derived calculations, Structure summary
