2CX1 | pdb_00002cx1

Crystal structure of a PUA domain (APE0525) from the Aeropyrum pernix K1 (tartrate complex)

• PDB DOI: https://doi.org/10.2210/pdb2CX1/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Aeropyrum pernix K1
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2005-06-27 Released: 2005-12-27
• Deposition Author(s): Mizohata, E., Morita, S., Nagano, K., Uda, H., Terada, T., Shirouzu, M., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.192 (Depositor), 0.193 (DCC)
• R-Value Work:
  0.163 (Depositor), 0.163 (DCC)
• R-Value Observed:
  0.163 (Depositor)

Literature

Crystal structure of a PUA domain (APE0525) from the Aeropyrum pernix K1 (tartrate complex)

Mizohata, E., Morita, S., Nagano, K., Uda, H., Terada, T., Shirouzu, M., Yokoyama, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 21.2 kDa
• Atom Count: 1,633
• Modeled Residue Count: 184
• Deposited Residue Count: 187
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hypothetical protein APE0525	A	187	Aeropyrum pernix K1	Mutation(s): 3  Gene Names: APE0525
UniProt
Find proteins for Q9YEQ6 (Aeropyrum pernix (strain ATCC 700893 / DSM 11879 / JCM 9820 / NBRC 100138 / K1)) Explore Q9YEQ6  Go to UniProtKB:  Q9YEQ6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
TLA	B [auth A]	L(+)-TARTARIC ACID C4 H6 O6 FEWJPZIEWOKRBE-JCYAYHJZSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.192 (Depositor), 0.193 (DCC)
• R-Value Work:  0.163 (Depositor), 0.163 (DCC)
• R-Value Observed: 0.163 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 39.271	α = 90
b = 49.139	β = 103.21
c = 53.491	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2005-12-27
Deposition Author(s): Mizohata, E., Morita, S., Nagano, K., Uda, H., Terada, T., Shirouzu, M., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2005-12-27
  Type: Initial release

• Version 1.1: 2008-04-30
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Source and taxonomy, Version format compliance
• Version 1.3: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
