2C1O | pdb_00002c1o

ENAIIHis Fab fragment in the free form


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.75 Å
  • R-Value Free:
    0.301 (Depositor)
  • R-Value Work:
    0.218 (Depositor), 0.219 (DCC)
  • R-Value Observed:
    0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2C1O

This is version 1.5 of the entry. See complete history

Literature

Crystal Structures of an Enantioselective Fab-Fragment in Free and Complex Forms.

Parkkinen, T.Nevanen, T.K.Koivula, A.Rouvinen, J.

(2006) J Mol Biology 357: 471

  • DOI: https://doi.org/10.1016/j.jmb.2005.12.045
  • Primary Citation Related Structures:
    2C1O, 2C1P

  • PubMed Abstract:

    Enantioselective antibodies can separate the enantiomers of a chiral compound in a highly specific manner. We have recently reported the cloning and applications of a recombinant Fab-fragment, ENA11His, in the enantioseparation of a drug candidate, finrozole, which contains two chiral centers. Here, the crystal structures of this enantioselective antibody Fab-fragment are determined in the absence of the hapten at a resolution of 2.75 A, and in the presence of the hapten at 2.05 A resolution. The conformation of the protein was found to be similar in both free and complex forms. The hapten molecule was tightly bound in a deep cleft between the light and heavy chains of the Fab-fragment. The complex structure also allowed us to describe the molecular basis for enantioselectivity and to deduce the absolute configurations of all the four different stereoisomers (a-d) of finrozole. The ENA11His antibody fragment selectively binds the SR (a) enantiomer from the racemic mixture of a and d-enantiomers, thus allowing separation from the pharmacologically most active RS enantiomer (d). In particular, Asp95 and Asn35 of the H-chain in the ENA11 His antibody seem to provide this specificity through hydrogen bonding.


  • Organizational Affiliation
    • Department of Chemistry, University of Joensuu, PO Box 111, FIN-80101 Joensuu, Finland.

Macromolecule Content

  • Total Structure Weight: 103.17 kDa
  • Atom Count: 6,848
  • Modeled Residue Count: 870
  • Deposited Residue Count: 944
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
IGK-C PROTEINA,
D [auth L]
254Mus musculusMutation(s): 0
UniProt
Find proteins for Q58EU8 (Mus musculus)
Explore Q58EU8
Go to UniProtKB:  Q58EU8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ58EU8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
IGH-4 PROTEINB,
C [auth H]
218Mus musculusMutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.75 Å
  • R-Value Free:  0.301 (Depositor)
  • R-Value Work:  0.218 (Depositor), 0.219 (DCC)
  • R-Value Observed: 0.218 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.805α = 90
b = 88.68β = 90
c = 141.441γ = 90
Software Package:
Software NamePurpose
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-01-25
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-07-24
    Changes: Data collection
  • Version 1.4: 2023-12-13
    Changes: Data collection, Database references, Other, Refinement description
  • Version 1.5: 2024-11-13
    Changes: Structure summary
