2B42 | pdb_00002b42

Crystal structure of the Triticum xylanse inhibitor-I in complex with bacillus subtilis xylanase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.240 (Depositor), 0.248 (DCC)
  • R-Value Work:
    0.183 (Depositor), 0.192 (DCC)
  • R-Value Observed:
    0.188 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2B42

This is version 1.4 of the entry. See complete history

Literature

Identification of structural determinants for inhibition strength and specificity of wheat xylanase inhibitors TAXI-IA and TAXI-IIA.

Pollet, A.Sansen, S.Raedschelders, G.Gebruers, K.Rabijns, A.Delcour, J.A.Courtin, C.M.

(2009) FEBS J 276: 3916-3927

  • DOI: https://doi.org/10.1111/j.1742-4658.2009.07105.x
  • Primary Citation Related Structures:
    2B42, 3HD8

  • PubMed Abstract:

    Triticum aestivum xylanase inhibitor (TAXI)-type inhibitors are active against microbial xylanases from glycoside hydrolase family 11, but the inhibition strength and the specificity towards different xylanases differ between TAXI isoforms. Mutational and biochemical analyses of TAXI-I, TAXI-IIA and Bacillus subtilis xylanase A showed that inhibition strength and specificity depend on the identity of only a few key residues of inhibitor and xylanase [Fierens K et al. (2005) FEBS J 272, 5872-5882; Raedschelders G et al. (2005) Biochem Biophys Res Commun335, 512-522; Sorensen JF & Sibbesen O (2006) Protein Eng Des Sel 19, 205-210; Bourgois TM et al. (2007) J Biotechnol 130, 95-105]. Crystallographic analysis of the structures of TAXI-IA and TAXI-IIA in complex with glycoside hydrolase family 11 B. subtilis xylanase A now provides a substantial explanation for these observations and a detailed insight into the structural determinants for inhibition strength and specificity. Structures of the xylanaseinhibitor complexes show that inhibition is established by loop interactions with active-site residues and substrate-mimicking contacts in the binding subsites. The interaction of residues Leu292 of TAXI-IA and Pro294 of TAXI-IIA with the -2 glycon subsite of the xylanase is shown to be critical for both inhibition strength and specificity. Also, detailed analysis of the interaction interfaces of the complexes illustrates that the inhibition strength of TAXI is related to the presence of an aspartate or asparagine residue adjacent to the acid/base catalyst of the xylanase, and therefore to the pH optimum of the xylanase. The lower the pH optimum of the xylanase, the stronger will be the interaction between enzyme and inhibitor, and the stronger the resulting inhibition.


  • Organizational Affiliation
    • Laboratory of Food Chemistry and Biochemistry, Katholieke Universiteit Leuven, Belgium.

Macromolecule Content

  • Total Structure Weight: 59.26 kDa
  • Atom Count: 4,112
  • Modeled Residue Count: 548
  • Deposited Residue Count: 566
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
xylanase inhibitor-I381Triticum aestivumMutation(s): 0
UniProt
Find proteins for Q8H0K8 (Triticum aestivum)
Explore Q8H0K8
Go to UniProtKB:  Q8H0K8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8H0K8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Endo-1,4-beta-xylanase A185Bacillus subtilisMutation(s): 0
Gene Names: xynA
EC: 3.2.1.8
UniProt
Find proteins for P18429 (Bacillus subtilis (strain 168))
Explore P18429
Go to UniProtKB:  P18429
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP18429
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.240 (Depositor), 0.248 (DCC)
  • R-Value Work:  0.183 (Depositor), 0.192 (DCC)
  • R-Value Observed: 0.188 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.89α = 90
b = 95.34β = 122.24
c = 69.31γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
SCALAdata scaling
CNSrefinement
MOSFLMdata reduction
CCP4data scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-09-19
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-07-24
    Changes: Data collection, Refinement description
  • Version 1.4: 2024-10-16
    Changes: Data collection, Database references, Structure summary
