2B3M | pdb_00002b3m

Crystal structure of protein AF1124 from Archaeoglobus fulgidus

PDB DOI: https://doi.org/10.2210/pdb2B3M/pdb

Classification: Structural Genomics, Unknown Function
Organism(s): Archaeoglobus fulgidus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2005-09-20 Released: 2005-11-01
Deposition Author(s): Chang, C., Skarina, T., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.205 (Depositor), 0.195 (DCC)
R-Value Work:
0.177 (Depositor)
R-Value Observed:
0.179 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2B3M

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of protein AF1124 from Archaeoglobus fulgidus

Chang, C., Skarina, T., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 17.63 kDa
Atom Count: 1,347
Modeled Residue Count: 154
Deposited Residue Count: 159
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hypothetical protein AF1124	A	159	Archaeoglobus fulgidus	Mutation(s): 0
UniProt
Find proteins for O29141 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16)) Explore O29141 Go to UniProtKB: O29141
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O29141
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.205 (Depositor), 0.195 (DCC)
R-Value Work: 0.177 (Depositor)
R-Value Observed: 0.179 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.596	α = 90
b = 57.596	β = 90
c = 142.993	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2005-11-01

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2005-11-01
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Derived calculations, Version format compliance
Version 1.3: 2024-02-14
Changes: Data collection, Database references
