 29LV | pdb_000029lv

PanDDA analysis - Crystal structure of the Ubiquitin conjugating enzyme 4 from Leishmania major (LmUbC4) in complex with Z55290386


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.273 (Depositor), 0.260 (DCC)
  • R-Value Work:
    0.248 (Depositor), 0.232 (DCC)
  • R-Value Observed:
    0.249 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 29LV

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history.

Literature

UbC4 from Leishmania is a Druggable E2 Ubiquitin Conjugating Enzyme: Structural Basis and Fragment Hits for Future E2-Recruiting PROTAC Development.

Exertier, C., Antonelli, L., Liuzzi, A., Ruffa, M., Brufani, V., Colotti, G., Fiorillo, A., Ilari, A.

(2026) ACS Omega 11: 55759-55771

  • DOI: https://doi.org/10.1021/acsomega.6c05158
  • Primary Citation Related Structures:
    28HT, 29LM, 29LN, 29LO, 29LP, 29LQ, 29LR, 29LS, 29LT, 29LU, 29LV

  • PubMed Abstract:

    Leishmaniasis is a neglected disease that affects around two million people every year. Current treatments are often highly toxic or prone to resistance, underscoring the urgent need for new therapeutic strategies. PROTACs may offer a promising alternative, as they can potentially mitigate both toxicity and resistance. However, very little is known about the ubiquitin-proteasome system (UPS) in Leishmania . Notably, only two E3 ligases containing a CULT domain have been identified so far, and none carrying a von Hippel-Lindau (VHL) domainthe classical E3 ligase used by clinically advanced PROTACs. In this work, we take an important step toward understanding the UPS in Leishmania , and we propose that in this organism the UbC4 E2 enzyme, rather than an E3, may be directly exploited to develop a PROTAC able to engage a protein of interest. Here, we report the biochemical and structural characterization of the Leishmania major ubiquitin-conjugating enzyme 4 (UbC4). Through a fragment screening campaign, we identified 10 fragments binding to distinct cavities on UbC4. Among these, five interact with the same noncatalytic pocket that is poorly conserved in humans, while one fragment binds near the catalytic cysteine. Using DeepFrag predictions and molecular docking, we explored fragment elongation strategies to enhance affinity for their respective binding sites, with the goal of guiding the development of E2-recruiting PROTACs or UPS inhibitors for the treatment of leishmaniasis.


  • Organizational Affiliation:
    • Institute of Molecular Biology and Pathology, Italian National Research Council (IBPM-CNR), c/o Department of Biochemical Sciences, Sapienza University of Rome, Ed. CU027, P.le A. Moro 5, 00185 Rome, Italy.

Macromolecule Content

  • Total Structure Weight: 38.85 kDa
  • Atom Count: 2,774
  • Modeled Residue Count: 315
  • Deposited Residue Count: 334
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ubiquitin-conjugating enzyme E2 H
A, B
167Leishmania majorMutation(s): 0
Gene Names: LMJF_32_0700
UniProt
Find proteins for Q4Q5L3 (Leishmania major)
Explore Q4Q5L3
Go to UniProtKB:  Q4Q5L3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4Q5L3
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.273 (Depositor), 0.260 (DCC)
  • R-Value Work:  0.248 (Depositor), 0.232 (DCC)
  • R-Value Observed: 0.249 (Depositor)
Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 115.814α = 90
b = 115.814β = 90
c = 153.21γ = 120
Software Package:
Software NamePurpose
BUSTERrefinement
PDB_EXTRACTdata extraction
xia2data reduction
xia2data scaling
DIMPLEphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
iNEXT-DiscoveryEuropean UnionPID 32193

Revision History  (Full details and data files)

  • Version 1.0: 2026-09-23
    Type: Initial release
  • Version 1.1: 2026-10-07
    Changes: Database references
