29HQ | pdb_000029hq

IAPP S20G growth-phase fibril polymorph 3PF-LJ

PDB DOI: https://doi.org/10.2210/pdb29HQ/pdb
EM Map EMD-57189: EMDB EMDataResource

Classification: STRUCTURAL PROTEIN
Organism(s): Homo sapiens
Mutation(s): Yes

Deposited: 2026-03-12 Released: 2026-08-26
Deposition Author(s): Lovestam, S., Scheres, S.H.W.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.50 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 29HQ

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM image processing of amyloid filaments in RELION-5.1

Lovestam, S., Shi, J., Li, D.B., Scheres, S.H.W.

To be published.

Macromolecule Content

Total Structure Weight: 46.25 kDa
Atom Count: 3,095
Modeled Residue Count: 430
Deposited Residue Count: 450
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Islet amyloid polypeptide	A B C D [auth E] E [auth F] A, B, C, D [auth E], E [auth F], F [auth G], G [auth I], H [auth J], I [auth K], J [auth M], K [auth N], L [auth O], M [auth Q], N [auth R], O [auth S]	30	Homo sapiens	Mutation(s): 2
UniProt & NIH Common Fund Data Resources
Find proteins for P10997 (Homo sapiens) Explore P10997 Go to UniProtKB: P10997
GTEx: ENSG00000121351
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P10997
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.50 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	5.1

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-26

Deposition Author(s):

Scheres, S.H.W.

Funding Organization	Location	Grant Number
Medical Research Council (MRC, United Kingdom)	United Kingdom	--

Revision History (Full details and data files)

Version 1.0: 2026-08-26
Type: Initial release
