27QA | pdb_000027qa

Dictyostelium discoideum cytoplasmic dynein motor domain in the presence of ADP (Apo state 1)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.76 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 27QA

This is version 1.0 of the entry. See complete history

Literature

ADP-Bound States of Cytoplasmic Dynein: Cryo-electron Microscopy Reveals a Two-Step Post-Power-Stroke Transition and Roles of Regulatory ATPase Sites.

Imai, H.Kanazawa, R.Maeshima, T.Tran, D.P.Shimo-Kon, R.Tokita, H.Miyata, T.Makino, F.Fujita, J.Kato, T.Kitao, A.Namba, K.Kon, T.

(2026) J Mol Biol : 169977-169977

  • DOI: https://doi.org/10.1016/j.jmb.2026.169977
  • Primary Citation Related Structures:
    27PT, 27PY, 27PZ, 27QA, 27QB

  • PubMed Abstract:

    Cytoplasmic dynein is essential for intracellular transport and cell division, and its dysfunction is implicated in severe neurological disorders. Its motility is driven by the primary ATPase site in the AAA1 module and allosterically modulated by regulatory ATPase sites in the AAA3 and AAA4 modules. Despite recent structural advances, post-force-generating (post-power-stroke) transitions and the structural basis of AAA3/AAA4-mediated regulation remain elusive. Using cryo-electron microscopy, we captured intermediate structures of Dictyostelium discoideum cytoplasmic dynein. We identified two distinct ADP-bound states and two apo states, the latter comprising a partially nucleotide-free state with ADP retained at the AAA3 and AAA4 ATPase sites and a fully nucleotide-free state. For the AAA1 ATPase site, our structures and molecular dynamics simulations suggest a dynamic equilibrium between two ADP-bound states. In this model, linker swing and docking onto the AAA5 module can be driven by thermal fluctuations while ADP remains bound at the AAA1 ATPase site, shifting the motor from a canonical ADP-bound state to a metastable apo-like conformation with reduced ADP affinity. This transition could provide a framework for tension-sensing coordination. For the AAA3 and AAA4 ATPase sites, comparison of the partially and fully nucleotide-free apo structures indicates that ADP release induces localized outward tilting of the corresponding large submodules. We propose that this rearrangement displaces the AAA4 Pre-Sensor-I insert from the linker, thereby disfavoring the recovery stroke and stabilizing an inactive state. Together, our findings provide a mechanistic model in which coordinated conformational dynamics across multiple ATPase sites govern dynein's chemomechanical cycle.


  • Organizational Affiliation
    • Department of Biological Sciences, Graduate School of Science, The University of Osaka, 1-1 Machikaneyama-cho, Toyonaka, Osaka 560-0043, Japan.

Macromolecule Content

  • Total Structure Weight: 385.72 kDa
  • Atom Count: 24,612
  • Modeled Residue Count: 3,046
  • Deposited Residue Count: 3,367
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Dynein heavy chain, cytoplasmic3,367Dictyostelium discoideum AX2Mutation(s): 0
Gene Names: dhcADDB_G0276355
UniProt
Find proteins for P34036 (Dictyostelium discoideum)
Explore P34036
Go to UniProtKB:  P34036
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP34036
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.76 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.21_5207
RECONSTRUCTIONcryoSPARC4.4.1

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)JapanJP16K07327
Japan Society for the Promotion of Science (JSPS)JapanJP21K06096
Japan Society for the Promotion of Science (JSPS)JapanJP24K09395
Japan Society for the Promotion of Science (JSPS)JapanJP17H03665
Japan Society for the Promotion of Science (JSPS)JapanJP24H02259
Japan Society for the Promotion of Science (JSPS)JapanJP23H02445

Revision History  (Full details and data files)

  • Version 1.0: 2026-08-26
    Type: Initial release
