25YJ | pdb_000025yj

Cryo-EM structure of the V1 domain of V-ATPase from rat brain, state 1

• PDB DOI: https://doi.org/10.2210/pdb25YJ/pdb
• EM Map EMD-80463: EMDB EMDataResource

• Classification: MOTOR PROTEIN
• Organism(s): Rattus norvegicus
• Mutation(s): No


• Deposited: 2026-04-22 Released: 2026-10-28
• Deposition Author(s): Nishida, Y., Ueda, F., Yokoyama, K.
• Funding Organization(s): Japan Society for the Promotion of Science (JSPS)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.25 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental

Literature

Cryo-EM structure of the V1 domain of V-ATPase from rat brain, state 1

Nishida, Y., Ueda, F., Yokoyama, K.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 16-mer - A3B3C3D3E2F1G1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 16-mer - A6B3C3D2E1F1 Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Hetero 12-mer - A3B3C3D3

Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Hetero 12-mer - A3B3C3D3

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 677.07 kDa
• Atom Count: 35,446
• Modeled Residue Count: 4,521
• Deposited Residue Count: 6,018
• Unique protein chains: 7

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
V-type proton ATPase catalytic subunit A	A, B, C	647	Rattus norvegicus	Mutation(s): 0  EC: 7.1.2.2
UniProt
Find proteins for D4A133 (Rattus norvegicus) Explore D4A133  Go to UniProtKB:  D4A133

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
V-type proton ATPase subunit D	D [auth H]	247	Rattus norvegicus	Mutation(s): 0
UniProt
Find proteins for F7EUL0 (Rattus norvegicus) Explore F7EUL0  Go to UniProtKB:  F7EUL0

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
V-type proton ATPase subunit E 1	E [auth I], F [auth J], G [auth K]	226	Rattus norvegicus	Mutation(s): 0
UniProt
Find proteins for Q6PCU2 (Rattus norvegicus) Explore Q6PCU2  Go to UniProtKB:  Q6PCU2

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
V-type proton ATPase subunit F	H [auth L]	119	Rattus norvegicus	Mutation(s): 0
UniProt
Find proteins for P50408 (Rattus norvegicus) Explore P50408  Go to UniProtKB:  P50408

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
V-type proton ATPase subunit G	I [auth M], J [auth N], K [auth O]	118	Rattus norvegicus	Mutation(s): 0
UniProt
Find proteins for Q8R2H0 (Rattus norvegicus) Explore Q8R2H0  Go to UniProtKB:  Q8R2H0

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Effector protein SidK	L [auth Q], M [auth R]	573	Rattus norvegicus	Mutation(s): 0

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
V-type proton ATPase subunit B, brain isoform	N [auth D], O [auth E], P [auth F]	511	Rattus norvegicus	Mutation(s): 0
UniProt
Find proteins for P62815 (Rattus norvegicus) Explore P62815  Go to UniProtKB:  P62815

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ADP (Subject of Investigation/LOI)	Q [auth C]	ADENOSINE-5'-DIPHOSPHATE C10 H15 N5 O10 P2 XTWYTFMLZFPYCI-KQYNXXCUSA-N
MG (Subject of Investigation/LOI)	R [auth C]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.25 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	4.0
MODEL REFINEMENT	PHENIX	1.20.1_4487

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-10-28
Deposition Author(s): Nishida, Y., Ueda, F., Yokoyama, K.

---

Funding Organization	Location	Grant Number
Japan Society for the Promotion of Science (JSPS)	Japan	23H02453

Revision History

• Version 1.0: 2026-10-28
  Type: Initial release
