25HW | pdb_000025hw

Cryo-EM structure of Pseudomonas aeruginosa FtsQBLWI


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.28 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 25HW

This is version 1.0 of the entry. See complete history

Literature

Structural, functional, and mechanistic studies of the bacterial divisome FtsWIQBL in complex with antibiotics.

Zhu, S.Hu, Y.Wang, R.Li, D.Zhang, Z.Dong, C.

(2026) Structure

  • DOI: https://doi.org/10.1016/j.str.2026.07.005
  • Primary Citation Related Structures:
    25HR, 25HS, 25HW

  • PubMed Abstract:

    Septal peptidoglycan (sPG) biosynthesis during bacterial cell division is driven by the dynamic divisome complex. Its core components, glycosyltransferase FtsW and transpeptidase FtsI are responsible for glycan chain polymerization and crosslinking, respectively. FtsI is also the target of β-lactams. The essential membrane complex FtsQ-FtsB-FtsL regulates FtsWI enzymatic activity. However, the mechanism of FtsQBLWI-mediated sPG synthesis and β-lactam-induced conformational changes have remained elusive. Here, we present cryo-electron microscopy (cryo-EM) structures of the Pseudomonas aeruginosa FtsQBLWI complex in the apo state and bound to aztreonam or imipenem. Our work reveals intricate structural details, including the putative substrate-binding cavities of FtsW, FtsI-mediated allosteric activation of FtsW, and β-lactam-triggered conformational rearrangements. Collectively, these structural, genetic and biochemical analyses reveal the mechanism of FtsQBLWI-controlled sPG synthesis and β-lactam action on this complex, providing a molecular basis for optimizing existing β-lactams and developing novel antibiotics.


  • Organizational Affiliation
    • Department of Thyroid and Breast Surgery, Zhongnan Hospital of Wuhan University, School of Pharmaceutical Sciences, Wuhan University, Wuhan 430071, China; Key Laboratory of Combinatorial Biosynthesis and Drug Discovery, Ministry of Education, and School of Pharmaceutical Sciences, Wuhan University, Wuhan 430071, China.

Macromolecule Content

  • Total Structure Weight: 161.06 kDa
  • Atom Count: 9,980
  • Modeled Residue Count: 1,284
  • Deposited Residue Count: 1,456
  • Unique protein chains: 5

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cell division protein FtsLA [auth D]97Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: ftsLPA4419
UniProt
Find proteins for Q9HVZ6 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9HVZ6
Go to UniProtKB:  Q9HVZ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HVZ6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Cell division protein FtsBB [auth E]94Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: ftsBPA3634
UniProt
Find proteins for Q9HXZ6 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9HXZ6
Go to UniProtKB:  Q9HXZ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HXZ6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Cell division protein FtsQ287Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: ftsQPA4409
UniProt
Find proteins for G3XDA7 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore G3XDA7
Go to UniProtKB:  G3XDA7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG3XDA7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Probable peptidoglycan glycosyltransferase FtsWD [auth A]399Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: ftsWPA4413
EC: 2.4.99.28
UniProt
Find proteins for Q9HW00 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9HW00
Go to UniProtKB:  Q9HW00
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HW00
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Peptidoglycan D,D-transpeptidase FtsIE [auth B]579Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: ftsIpbpBPA4418
EC: 3.4.16.4
UniProt
Find proteins for G3XD46 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore G3XD46
Go to UniProtKB:  G3XD46
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG3XD46
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.28 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19.2_4158
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data

  • Released Date: 2026-08-12
  • Deposition Author(s): Zhu, S.

Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China2022YFA1303500

Revision History  (Full details and data files)

  • Version 1.0: 2026-08-12
    Type: Initial release
