24ZQ | pdb_000024zq

The alpha amylase AmyY complexed with an acarbose-derived trisaccharide.

PDB DOI: https://doi.org/10.2210/pdb24ZQ/pdb

Classification: HYDROLASE
Organism(s): Alkalimonas sp. NCh-2
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2026-03-25 Released: 2026-08-05
Deposition Author(s): Zhao, F., Xu, T.T., Chen, X.L., Zhang, Y.Z.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.228 (Depositor), 0.225 (DCC)
R-Value Work:
0.189 (Depositor), 0.189 (DCC)
R-Value Observed:
0.190 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 24ZQ

This is version 1.0 of the entry. See complete history.

Literature

The alpha amylase AmyY complexed with an acarbose-derived trisaccharide.

Zhao, F., Xu, T.T., Chen, X.L., Zhang, Y.Z.

To be published.

Macromolecule Content

Total Structure Weight: 115.15 kDa
Atom Count: 8,277
Modeled Residue Count: 924
Deposited Residue Count: 1,000
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alpha-amylase	A, B	500	Alkalimonas sp. NCh-2	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
4,6-dideoxy-4-{[(1S,4R,5S,6S)-4,5,6-trihydroxy-3-(hydroxymethyl)cyclohex-2-en-1-yl]amino}-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose	C, D	2	N/A	N/A	Interactions Focus chain C Focus chain D Interactions & Density Focus chain C Focus chain D

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
B3P Query on B3P Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	2-[3-(2-HYDROXY-1,1-DIHYDROXYMETHYL-ETHYLAMINO)-PROPYLAMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₁₁ H₂₆ N₂ O₆ HHKZCCWKTZRCCL-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
TRS Query on TRS Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain G [auth B] SDF format, chain H [auth B] SDF format, chain I [auth B] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B] mmCIF format, chain H [auth B] mmCIF format, chain I [auth B]	E [auth A], G [auth B], H [auth B], I [auth B]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Interactions & Density Focus chain E [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B]

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900110 Query on PRD_900110	C, D	acarbose-derived trisaccharide	Oligosaccharide / Inhibitor		Interactions Focus chain C Focus chain D Interactions & Density Focus chain C Focus chain D

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.228 (Depositor), 0.225 (DCC)
R-Value Work: 0.189 (Depositor), 0.189 (DCC)
R-Value Observed: 0.190 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 140.207	α = 90
b = 140.207	β = 90
c = 84.034	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
xia2	data reduction
xia2	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-05

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2026-08-05
Type: Initial release
