1YLX | pdb_00001ylx

Crystal Structure of a Protein of Unknown Function from Bacillus stearothermophilus

PDB DOI: https://doi.org/10.2210/pdb1YLX/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Geobacillus stearothermophilus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2005-01-19 Released: 2005-05-31
Deposition Author(s): Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.247 (Depositor), 0.253 (DCC)
R-Value Work:
0.229 (Depositor), 0.236 (DCC)
R-Value Observed:
0.229 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1YLX

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of APC35702, a hypothetical protein from Bacillus stearothermophilus

Duke, N.E.C., Moy, S., Li, H., Collart, F., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 24.59 kDa
Atom Count: 1,735
Modeled Residue Count: 200
Deposited Residue Count: 206
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hypothetical protein APC35702	A, B	103	Geobacillus stearothermophilus	Mutation(s): 0
UniProt
Find proteins for Q5KZY7 (Geobacillus kaustophilus (strain HTA426)) Explore Q5KZY7 Go to UniProtKB: Q5KZY7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5KZY7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.247 (Depositor), 0.253 (DCC)
R-Value Work: 0.229 (Depositor), 0.236 (DCC)
R-Value Observed: 0.229 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.189	α = 90
b = 70.156	β = 90
c = 81.361	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
DM	phasing
SOLVE	phasing
RESOLVE	phasing
O	model building
Coot	model building
CCP4	phasing
CNS	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2005-05-31

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2005-05-31
Type: Initial release
Version 1.1: 2008-04-30
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2024-10-30
Changes: Data collection, Database references, Derived calculations, Structure summary
