1VJT | pdb_00001vjt

Crystal structure of Alpha-glucosidase (TM0752) from Thermotoga maritima at 2.50 A resolution

PDB DOI: https://doi.org/10.2210/pdb1VJT/pdb

Classification: HYDROLASE
Organism(s): Thermotoga maritima
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2004-03-22 Released: 2004-03-30
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.256 (Depositor), 0.202 (DCC)
R-Value Work:
0.194 (Depositor), 0.204 (DCC)
R-Value Observed:
0.198 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1VJT

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of Alpha-glucosidase (TM0752) from Thermotoga maritima at 2.50 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 58.26 kDa
Atom Count: 3,960
Modeled Residue Count: 471
Deposited Residue Count: 483
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
alpha-glucosidase	A	483	Thermotoga maritima	Mutation(s): 15 Gene Names: TM0752 EC: 3.2.1.139
UniProt
Find proteins for Q9WZL1 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9WZL1 Go to UniProtKB: Q9WZL1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9WZL1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD Query on NAD Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.256 (Depositor), 0.202 (DCC)
R-Value Work: 0.194 (Depositor), 0.204 (DCC)
R-Value Observed: 0.198 (Depositor)

Diffraction Data:

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 75.722	α = 90
b = 79.815	β = 101.99
c = 89.222	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
autoSHARP	phasing
RESOLVE	model building
REFMAC	refinement
RESOLVE	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2004-03-30

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2004-03-30
Type: Initial release
Version 1.1: 2008-04-26
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.3: 2023-01-25
Changes: Database references, Derived calculations
Version 1.4: 2024-11-06
Changes: Data collection, Structure summary
