1VJR | pdb_00001vjr

Crystal structure of 4-nitrophenylphosphatase (TM1742) from Thermotoga maritima at 2.40 A resolution

PDB DOI: https://doi.org/10.2210/pdb1VJR/pdb

Classification: HYDROLASE
Organism(s): Thermotoga maritima
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2004-03-22 Released: 2004-03-30
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.194 (Depositor), 0.192 (DCC)
R-Value Work:
0.164 (Depositor), 0.165 (DCC)
R-Value Observed:
0.165 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1VJR

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of 4-nitrophenylphosphatase (TM1742) from Thermotoga maritima at 2.40 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 30.68 kDa
Atom Count: 2,366
Modeled Residue Count: 261
Deposited Residue Count: 271
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
4-nitrophenylphosphatase	A	271	Thermotoga maritima	Mutation(s): 6 Gene Names: TM1742 EC: 3.1.3.41
UniProt
Find proteins for Q9X264 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9X264 Go to UniProtKB: Q9X264
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9X264
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NI Query on NI Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.194 (Depositor), 0.192 (DCC)
R-Value Work: 0.164 (Depositor), 0.165 (DCC)
R-Value Observed: 0.165 (Depositor)

Diffraction Data:

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.998	α = 90
b = 93.998	β = 90
c = 160.365	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
SOLVE	phasing
autoSHARP	phasing
REFMAC	refinement
CCP4	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2004-03-30

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2004-03-30
Type: Initial release
Version 1.1: 2008-04-26
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.3: 2023-01-25
Changes: Database references, Derived calculations
Version 1.4: 2024-11-13
Changes: Data collection, Structure summary
