1T9Y

Structural Basis of Multidrug Transport by the AcrB Multidrug Efflux Pump


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.64 Å
  • R-Value Free: 0.340
  • R-Value Work: 0.277
  • R-Value Observed: 0.278

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

A Periplasmic Drug-Binding Site of the AcrB Multidrug Efflux Pump: a Crystallographic and Site-Directed Mutagenesis Study

Yu, E.W.Aires, J.R.McDermott, G.Nikaido, H.

(2005) J Bacteriol 187: 6804-6815

  • DOI: https://doi.org/10.1128/JB.187.19.6804-6815.2005
  • Primary Citation of Related Structures:
    1T9T, 1T9U, 1T9V, 1T9W, 1T9X, 1T9Y

  • PubMed Abstract:

    The Escherichia coli AcrB multidrug efflux pump is a membrane protein that recognizes many structurally dissimilar toxic compounds. We previously reported the X-ray structures of four AcrB-ligand complexes in which the ligands were bound to the wall of the extremely large central cavity in the transmembrane domain of the pump. Genetic studies, however, suggested that discrimination between the substrates occurs mainly in the periplasmic domain rather than the transmembrane domain of the pump. We here describe the crystal structures of the AcrB mutant in which Asn109 was replaced by Ala, with five structurally diverse ligands, ethidium, rhodamine 6G, ciprofloxacin, nafcillin, and Phe-Arg-beta-naphthylamide. The ligands bind not only to the wall of central cavity but also to a new periplasmic site within the deep external depression formed by the C-terminal periplasmic loop. This depression also includes residues identified earlier as being important in the specificity. We show here that conversion into alanine of the Phe664, Phe666, or Glu673 residue in the periplasmic binding site produced significant decreases in the MIC of most agents in the N109A background. Furthermore, decreased MICs were also observed when these residues were mutated in the wild-type AcrB background, although the effects were more modest. The MIC data were also confirmed by assays of ethidium influx rates in intact cells, and our results suggest that the periplasmic binding site plays a role in the physiological process of drug efflux.


  • Organizational Affiliation

    Department of Molecular and Cell Biology, 16 Barker Hall, University of California, Berkeley, CA 94720-3202, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Acriflavine resistance protein B1,049Escherichia coliMutation(s): 1
Gene Names: acrBacrEb0462
Membrane Entity: Yes
UniProt
Find proteins for P31224 (Escherichia coli (strain K12))
Explore P31224
Go to UniProtKB:  P31224
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP31224
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MC2
Query on MC2

Download Ideal Coordinates CCD File
B [auth A],
C [auth A]
N2-(L-PHENYLALANYL)-N1-(NAPHTHALENYL)-L-ARIGNINAMIDE
C25 H30 N6 O2
ZNHUFUZDUQRKBB-VXKWHMMOSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.64 Å
  • R-Value Free: 0.340
  • R-Value Work: 0.277
  • R-Value Observed: 0.278
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 144.922α = 90
b = 144.922β = 90
c = 516.675γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
SCALEPACKdata scaling
MOLREPphasing
REFMACrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-10-04
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2018-10-31
    Changes: Advisory, Data collection, Derived calculations
  • Version 1.4: 2021-10-27
    Changes: Database references, Derived calculations
  • Version 1.5: 2024-02-14
    Changes: Data collection
