1T6L | pdb_00001t6l

Crystal Structure of the Human Cytomegalovirus DNA Polymerase Subunit, UL44


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free:
    0.268 (Depositor), 0.266 (DCC)
  • R-Value Work:
    0.235 (Depositor), 0.235 (DCC)
  • R-Value Observed:
    0.238 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1T6L

This is version 1.3 of the entry. See complete history

Literature

The Cytomegalovirus DNA Polymerase Subunit UL44 Forms a C Clamp-Shaped Dimer.

Appleton, B.A.Loregian, A.Filman, D.J.Coen, D.M.Hogle, J.M.

(2004) Mol Cell 15: 233-244

  • DOI: https://doi.org/10.1016/j.molcel.2004.06.018
  • Primary Citation Related Structures:
    1T6L

  • PubMed Abstract:

    The human cytomegalovirus DNA polymerase consists of a catalytic subunit, UL54, and a presumed processivity factor, UL44. We have solved the crystal structure of residues 1-290 of UL44 to 1.85 A resolution by multiwavelength anomalous dispersion. The structure reveals a dimer of UL44 in the shape of a C clamp. Each monomer of UL44 shares its overall fold with other processivity factors, including herpes simplex virus UL42, which is a monomer that binds DNA directly, and the sliding clamp, PCNA, which is a trimer that surrounds DNA, although these proteins share no obvious sequence homology. Analytical ultracentrifugation and gel filtration measurements demonstrated that UL44 also forms a dimer in solution, and substitution of large hydrophobic residues along the homodimer interface with alanine disrupted dimerization and decreased DNA binding. UL44 represents a hybrid processivity factor as it binds DNA directly like UL42, but forms a C clamp that may surround DNA like PCNA.


  • Organizational Affiliation
    • Department of Biological Chemistry and Molecular Pharmacology, Harvard Medical School, Boston, MA 02115, USA.

Macromolecule Content

  • Total Structure Weight: 32.58 kDa
  • Atom Count: 2,036
  • Modeled Residue Count: 249
  • Deposited Residue Count: 290
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA polymerase processivity factor290Human betaherpesvirus 5Mutation(s): 0
Gene Names: UL44
UniProt
Find proteins for P16790 (Human cytomegalovirus (strain AD169))
Explore P16790
Go to UniProtKB:  P16790
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP16790
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free:  0.268 (Depositor), 0.266 (DCC)
  • R-Value Work:  0.235 (Depositor), 0.235 (DCC)
  • R-Value Observed: 0.238 (Depositor)
Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.93α = 90
b = 53.93β = 90
c = 340.067γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling
SOLVEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-08-10
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-02-14
    Changes: Data collection, Database references
