 1SKZ | pdb_00001skz

PROTEASE INHIBITOR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Work:
    0.217 (Depositor), 0.213 (DCC)
  • R-Value Observed:
    0.217 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1SKZ

This is version 1.3 of the entry. See complete history.

Literature

X-ray structure of antistasin at 1.9 A resolution and its modelled complex with blood coagulation factor Xa.

Lapatto, R., Krengel, U., Schreuder, H.A., Arkema, A., de Boer, B., Kalk, K.H., Hol, W.G., Grootenhuis, P.D., Mulders, J.W., Dijkema, R., Theunissen, H.J., Dijkstra, B.W.

(1997) EMBO J 16: 5151-5161

  • DOI: https://doi.org/10.1093/emboj/16.17.5151
  • Primary Citation Related Structures:
    1SKZ

  • PubMed Abstract:

    The three-dimensional structure of antistasin, a potent inhibitor of blood coagulation factor Xa, from the Mexican leech Haementeria officinalis was determined at 1.9 A resolution by X-ray crystallography. The structure reveals a novel protein fold composed of two homologous domains, each resembling the structure of hirustasin, a related 55-residue protease inhibitor. However, hirustasin has a different overall shape than the individual antistasin domains, it contains four rather than two beta-strands, and does not inhibit factor Xa. The two antistasin domains can be subdivided into two similarly sized subdomains with different relative orientations. Consequently, the domain shapes are different, the N-terminal domain being wedge-shaped and the C-terminal domain flat. Docking studies suggest that differences in domain shape enable the N-terminal, but not C-terminal, domain of antistasin to bind and inhibit factor Xa, even though both have a very similar reactive site. Furthermore, a putative exosite binding region could be defined in the N-terminal domain of antistasin, comprising residues 15-17, which is likely to interact with a cluster of positively charged residues on the factor Xa surface (Arg222/Lys223/Lys224). This exosite binding region explains the specificity and inhibitory potency of antistasin towards factor Xa. In the C-terminal domain of antistasin, these exosite interactions are prevented due to the different overall shape of this domain.


  • Organizational Affiliation:
    • Laboratory of Biophysical Chemistry and BIOSON Research Institute, Department of Chemistry, University of Groningen, Nijenborgh 4, 9747 AG Groningen, The Netherlands.

Macromolecule Content

  • Total Structure Weight: 13.41 kDa
  • Atom Count: 878
  • Modeled Residue Count: 104
  • Deposited Residue Count: 119
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ANTISTASIN119Haementeria officinalisMutation(s): 0
UniProt
Find proteins for P15358 (Haementeria officinalis)
Explore P15358
Go to UniProtKB:  P15358
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP15358
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CL

Query on CL



Download:Ideal Coordinates CCD File
B [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Work:  0.217 (Depositor), 0.213 (DCC)
  • R-Value Observed: 0.217 (Depositor)
Space Group: I 4 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.5α = 90
b = 76.5β = 90
c = 86.6γ = 90
Software Package:
Software NamePurpose
XDSdata scaling
XSCALEdata scaling
X-PLORmodel building
X-PLORrefinement
XDSdata reduction
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-10-22
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-11-20
    Changes: Data collection, Database references, Derived calculations, Structure summary
