1SGJ | pdb_00001sgj

Crystal structure of citrate lyase beta subunit

PDB DOI: https://doi.org/10.2210/pdb1SGJ/pdb

Classification: LYASE
Organism(s): Deinococcus radiodurans
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2004-02-23 Released: 2004-08-17
Deposition Author(s): Eswaramoorthy, S., Swaminathan, S., Burley, S.K., New York SGX Research Center for Structural Genomics (NYSGXRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.84 Å
R-Value Free:
0.243 (Depositor)
R-Value Work:
0.227 (Depositor)
R-Value Observed:
0.227 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1SGJ

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of citrate lyase beta subunit

Eswaramoorthy, S., Swaminathan, S.

To be published.

Macromolecule Content

Total Structure Weight: 90.5 kDa
Atom Count: 5,739
Modeled Residue Count: 693
Deposited Residue Count: 852
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
citrate lyase, beta subunit	A, B, C	284	Deinococcus radiodurans	Mutation(s): 0 EC: 4.1
UniProt
Find proteins for Q9RUZ0 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / CCUG 27074 / LMG 4051 / NBRC 15346 / NCIMB 9279 / VKM B-1422 / R1)) Explore Q9RUZ0 Go to UniProtKB: Q9RUZ0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9RUZ0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
OAA Query on OAA Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain F [auth B] SDF format, chain H [auth C] MOL2 format, chain D [auth A] MOL2 format, chain F [auth B] MOL2 format, chain H [auth C] mmCIF format, chain D [auth A] mmCIF format, chain F [auth B] mmCIF format, chain H [auth C]	D [auth A], F [auth B], H [auth C]	OXALOACETATE ION C₄ H₃ O₅ KHPXUQMNIQBQEV-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain F [auth B] Focus chain H [auth C]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain G [auth B] SDF format, chain I [auth C] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] MOL2 format, chain I [auth C] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B] mmCIF format, chain I [auth C]	E [auth A], G [auth B], I [auth C]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain G [auth B] Focus chain I [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.84 Å
R-Value Free: 0.243 (Depositor)
R-Value Work: 0.227 (Depositor)
R-Value Observed: 0.227 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.61	α = 68.26
b = 73.28	β = 83.51
c = 74.48	γ = 68.38

Software Package:

Software Name	Purpose
MARMAD	data collection
HKL-2000	data reduction
SCALEPACK	data scaling
SOLVE	phasing
CNS	refinement
MARMAD	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2004-08-17

Deposition Author(s):

Eswaramoorthy, S.

Swaminathan, S.

New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History (Full details and data files)

Version 1.0: 2004-08-17
Type: Initial release
Version 1.1: 2008-04-29
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2021-02-03
Changes: Derived calculations, Structure summary
Version 1.4: 2024-02-14
Changes: Data collection, Database references
