1S4F | pdb_00001s4f

Crystal Structure of RNA-dependent RNA polymerase construct 2 from bovine viral diarrhea virus (BVDV)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.303 (Depositor), 0.299 (DCC)
  • R-Value Work:
    0.254 (Depositor), 0.251 (DCC)
  • R-Value Observed:
    0.254 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1S4F

This is version 1.3 of the entry. See complete history

Literature

The structure of the RNA-dependent RNA polymerase from bovine viral diarrhea virus establishes the role of GTP in de novo initiation.

Choi, K.H.Groarke, J.M.Young, D.C.Kuhn, R.J.Smith, J.L.Pevear, D.C.Rossmann, M.G.

(2004) Proc Natl Acad Sci U S A 101: 4425-4430

  • DOI: https://doi.org/10.1073/pnas.0400660101
  • Primary Citation Related Structures:
    1S48, 1S49, 1S4F

  • PubMed Abstract:

    The bovine viral diarrhea virus (BVDV) RNA-dependent RNA polymerase can initiate RNA replication by a de novo mechanism without a primer. The structure of BVDV polymerase, determined to 2.9-A resolution, contains a unique N-terminal domain, in addition to the fingers, palm, and thumb domains common to other polymerases. The structure of BVDV polymerase complexed with GTP, which is required for de novo (primer-independent) initiation, shows that GTP binds adjacent to the initiation NTP, suggesting that the GTP mimics a vestigial RNA product. Comparison of five monomers in two different crystal forms showed conformational changes in the fingertip region and in the thumb domain that may help to translocate the RNA template and product strands during elongation. The putative binding sites of previously reported BVDV inhibitors are also discussed.


  • Organizational Affiliation
    • Department of Biological Sciences, Purdue University, 915 West State Street, West Lafayette, IN 47907, USA.

Macromolecule Content

  • Total Structure Weight: 275.79 kDa
  • Atom Count: 18,714
  • Modeled Residue Count: 2,322
  • Deposited Residue Count: 2,404
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA-dependent RNA polymerase
A, B, C, D
601Bovine viral diarrhea virus 1Mutation(s): 0
UniProt
Find proteins for P19711 (Bovine viral diarrhea virus (isolate NADL))
Explore P19711
Go to UniProtKB:  P19711
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19711
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.303 (Depositor), 0.299 (DCC)
  • R-Value Work:  0.254 (Depositor), 0.251 (DCC)
  • R-Value Observed: 0.254 (Depositor)
Space Group: P 62 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 412.271α = 90
b = 412.271β = 90
c = 95.574γ = 120
Software Package:
Software NamePurpose
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-04-06
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2024-10-30
    Changes: Data collection, Database references, Structure summary
