1RJI

Solution Structure of BmKX, a novel potassium channel blocker from the Chinese Scorpion Buthus martensi Karsch


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 21
  • Selection Criteria: structures with the lowest energy

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

A novel short-chain peptide BmKX from the Chinese scorpion Buthus martensi karsch, sequencing, gene cloning and structure determination

Wang, C.-G.Cai, Z.Lu, W.Wu, J.Xu, Y.Shi, Y.Chi, C.-W.

(2005) Toxicon 45: 309-319

  • DOI: https://doi.org/10.1016/j.toxicon.2004.11.014
  • Primary Citation of Related Structures:
    1RJI

  • PubMed Abstract:

    Scorpion venom is a rich source of bioactive peptides. From the venom of Chinese scorpion Buthus martensi Karsch (BmK), a novel short chain peptide BmKX of 31-amino acid residues was purified, and its amino acid sequence and gene structure were determined. The gene of BmKX was composed of two exons interrupted by an 86-bp intron at the codon-7 upstream of the mature peptide. Although its gene structure is similar to those of other known scorpion toxins, its amino acid sequence, especially the cysteine framework, is different from those of all other known subfamilies of short-chain scorpion toxins. The solution structure of BmKX, determined with two-dimensional NMR spectroscopy, shows that BmKX also forms a typical cysteine-stabilized alpha/beta scaffold adopted by most short-chain scorpion toxins, consisting of a short 3(10)-helix and a two-stranded antiparallel beta-sheet, and the short N-terminal segment forms a pseudo-strand of the beta-sheet. However, the orientation between the helix and the beta-sheet is significantly different from the others, which might be the reason for its unique but still unclear physiological function.


  • Organizational Affiliation

    Shanghai Institute of Biochemistry and Cell Biology, Chinese Academy of Sciences, Yue-Yang Road 320, Shanghai 200031, People's Republic of China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
potassium channel toxin KX31N/AMutation(s): 0
UniProt
Find proteins for Q7Z0H4 (Mesobuthus martensii)
Explore Q7Z0H4
Go to UniProtKB:  Q7Z0H4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Z0H4
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 21
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-12-09
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-03-02
    Changes: Data collection, Database references, Derived calculations
  • Version 1.4: 2024-10-23
    Changes: Data collection, Structure summary
