1RDY | pdb_00001rdy

T-STATE STRUCTURE OF THE ARG 243 TO ALA MUTANT OF PIG KIDNEY FRUCTOSE 1,6-BISPHOSPHATASE EXPRESSED IN E. COLI


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.234 (Depositor)
  • R-Value Work:
    0.198 (Depositor)
  • R-Value Observed:
    0.198 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1RDY

This is version 1.5 of the entry. See complete history

Literature

Crystal structures of the active site mutant (Arg-243-->Ala) in the T and R allosteric states of pig kidney fructose-1,6-bisphosphatase expressed in Escherichia coli.

Stec, B.Abraham, R.Giroux, E.Kantrowitz, E.R.

(1996) Protein Sci 5: 1541-1553

  • DOI: https://doi.org/10.1002/pro.5560050810
  • Primary Citation Related Structures:
    1RDX, 1RDY, 1RDZ

  • PubMed Abstract:

    The active site of pig kidney fructose-1,6-bisphosphatase (EC 3.1.3.11) is shared between subunits, Arg-243 of one chain interacting with fructose-1,6-bisphosphate or fructose-2,6-bisphosphate in the active site of an adjacent chain. In this study, we present the X-ray structures of the mutant version of the enzyme with Arg-243 replaced by alanine, crystallized in both T and R allosteric states. Kinetic characteristics of the altered enzyme showed the magnesium binding and inhibition by AMP differed slightly; affinity for the substrate fructose-1,6-bisphosphate was reduced 10-fold and affinity for the inhibitor fructose-2,6-bisphosphate was reduced 1,000-fold (Giroux E, Williams MK, Kantrowitz ER, 1994, J Biol Chem 269:31404-31409). The X-ray structures show no major changes in the organization of the active site compared with wild-type enzyme, and the structures confirm predictions of molecular dynamics simulations involving Lys-269 and Lys-274. Comparison of two independent models of the T form structures have revealed small but significant changes in the conformation of the bound AMP molecules and small reorganization of the active site correlated with the presence of the inhibitor. The differences in kinetic properties of the mutant enzyme indicate the key importance of Arg-243 in the function of fructose-1,6-bisphosphatase. Calculations using the X-ray structures of the Arg-243-->Ala enzyme suggest that the role of Arg-243 in the wild-type enzyme is predominantly electrostatic in nature.


  • Organizational Affiliation
    • Department of Chemistry, Merkert Chemistry Center, Boston College, Chestnut Hill, Massachusetts 02167, USA.

Macromolecule Content

  • Total Structure Weight: 74.45 kDa
  • Atom Count: 5,322
  • Modeled Residue Count: 674
  • Deposited Residue Count: 674
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
FRUCTOSE 1,6-BISPHOSPHATASE
A, B
337Sus scrofaMutation(s): 1
Gene Names: CDNA
EC: 3.1.3.11
UniProt
Find proteins for P00636 (Sus scrofa)
Explore P00636
Go to UniProtKB:  P00636
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00636
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.234 (Depositor)
  • R-Value Work:  0.198 (Depositor)
  • R-Value Observed: 0.198 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 61.2α = 90
b = 166.75β = 90
c = 79.84γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
SDMSdata reduction
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-01-11
    Type: Initial release
  • Version 1.1: 2008-03-03
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Database references, Derived calculations, Other, Structure summary
  • Version 1.4: 2021-11-03
    Changes: Database references, Structure summary
  • Version 1.5: 2024-12-25
    Changes: Advisory, Data collection, Derived calculations, Structure summary
