1ONL | pdb_00001onl

Crystal structure of Thermus thermophilus HB8 H-protein of the glycine cleavage system


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.253 (Depositor), 0.252 (DCC)
  • R-Value Work:
    0.186 (Depositor), 0.185 (DCC)
  • R-Value Observed:
    0.186 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1ONL

This is version 1.3 of the entry. See complete history

Literature

Structure of Thermus thermophilus HB8 H-protein of the glycine-cleavage system, resolved by a six-dimensional molecular-replacement method.

Nakai, T.Ishijima, J.Masui, R.Kuramitsu, S.Kamiya, N.

(2003) Acta Crystallogr D Biol Crystallogr 59: 1610-1618

  • DOI: https://doi.org/10.1107/s0907444903014975
  • Primary Citation Related Structures:
    1ONL

  • PubMed Abstract:

    The glycine-cleavage system is a multi-enzyme complex consisting of four different components (the P-, H-, T- and L-proteins). Recombinant H-protein corresponding to that from Thermus thermophilus HB8 has been overexpressed, purified and crystallized. Synchrotron radiation from BL44B2 at SPring-8 was used to collect a native data set to 2.5 A resolution. The crystals belonged to the hexagonal space group P6(5) and contained three molecules per asymmetric unit, with a solvent content of 39%. Because of the large number of molecules within a closely packed unit cell, this structure was solved by six-dimensional molecular replacement with the program EPMR using the pea H-protein structure as a search model and was refined to an R factor of 0.189 and a free R factor of 0.256. Comparison with the pea H-protein reveals two highly conserved regions surrounding the lipoyl-lysine arm. Both of these regions are negatively charged and each has additional properties that are conserved in H-proteins from many species, suggesting that these regions are involved in intermolecular interactions. One region has previously been proposed to constitute an interaction surface with T-protein, while the other may be involved in an interaction with P-protein. Meanwhile, the lipoyl-lysine arm of the T. thermophilus H-protein was found to be more flexible than that of the pea H-protein, supporting the hypothesis that H-protein does not form a stable complex with L-protein during the reaction.


  • Organizational Affiliation
    • RIKEN Harima Institute/SPring-8, 1-1-1 Kouto, Mikazuki, Sayo-gun, Hyogo 679-5148, Japan. nakaix@spring8.or.jp

Macromolecule Content

  • Total Structure Weight: 42.28 kDa
  • Atom Count: 3,070
  • Modeled Residue Count: 381
  • Deposited Residue Count: 384
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
glycine cleavage system H protein
A, B, C
128Thermus thermophilusMutation(s): 0
Gene Names: GcvH
UniProt
Find proteins for Q5SKW9 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SKW9
Go to UniProtKB:  Q5SKW9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SKW9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.253 (Depositor), 0.252 (DCC)
  • R-Value Work:  0.186 (Depositor), 0.185 (DCC)
  • R-Value Observed: 0.186 (Depositor)
Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.775α = 90
b = 55.775β = 90
c = 191.19γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
SCALEPACKdata scaling
EPMRphasing
CNSrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-08-26
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-10-25
    Changes: Data collection, Database references, Refinement description
