1N8E | pdb_00001n8e

Fragment Double-D from Human Fibrin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.50 Å
  • R-Value Free:
    0.416 (Depositor)
  • R-Value Work:
    0.415 (Depositor)
  • R-Value Observed:
    0.415 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1N8E

This is version 1.3 of the entry. See complete history

Literature

The Crystal Structure of Fragment Double-D from Cross-Linked Lamprey Fibrin Reveals Isopeptide Linkages across an Unexpected D-D Interface

Yang, Z.Pandi, L.Doolittle, R.F.

(2002) Biochemistry 41: 15610-15617

  • DOI: https://doi.org/10.1021/bi026666i
  • Primary Citation Related Structures:
    1N73, 1N86, 1N8E

  • PubMed Abstract:

    The crystal structure of fragment double-D from factor XIII-cross-linked lamprey fibrin has been determined at 2.9 A resolution. The 180 kDa covalent dimer was cocrystallized with the peptide Gly-His-Arg-Pro-amide, which in many fibrinogens, but not that of lamprey, corresponds to the B-knob exposed by thrombin. The structure was determined by molecular replacement, a recently determined structure of lamprey fragment D being used as a search model. GHRPam was found in both the gamma- and beta-chain holes. Unlike the situation with fragment D, the crystal packing of the cross-linked double-D structure exhibits two different D-D interfaces, each gamma-chain facing gamma-chains on two other molecules. One of these (interface I) involves the asymmetric interface observed in all other D fragments and related structures. The other (interface II) encompasses a completely different set of residues. The two abutments differ in that interface I results in an "in line" arrangement of abutting molecules and the interface II in a "zigzag" arrangement. So far as can be determined (the electron density could only be traced on one side of the cross-links), it is the gamma-chains of the newly observed zigzag units (interface II) that are joined by the reciprocal epsilon-amino-gamma-glutamyl cross-links. Auspiciously, the same novel D-D interface was observed in two lower-resolution crystal structures of human double-D preparations that had been crystallized under unusual circumstances. These observations show that double-D structures are linked in a way that is sufficiently flexible to accommodate different D-D interfaces under different circumstances.


  • Organizational Affiliation
    • Center for Molecular Genetics, University of California at San Diego, La Jolla, CA 92093-0634, USA.

Macromolecule Content

  • Total Structure Weight: 169.81 kDa
  • Atom Count: 1,352
  • Modeled Residue Count: 1,352
  • Deposited Residue Count: 1,482
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Fibrin alpha/alpha-E chain
A, D
89Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P02671 (Homo sapiens)
Explore P02671
Go to UniProtKB:  P02671
PHAROS:  P02671
GTEx:  ENSG00000171560
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02671
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Fibrin beta chain
B, E
328Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P02675 (Homo sapiens)
Explore P02675
Go to UniProtKB:  P02675
PHAROS:  P02675
GTEx:  ENSG00000171564
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02675
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Fibrin gamma chain
C, F
324Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P02679 (Homo sapiens)
Explore P02679
Go to UniProtKB:  P02679
PHAROS:  P02679
GTEx:  ENSG00000171557
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02679
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.50 Å
  • R-Value Free:  0.416 (Depositor)
  • R-Value Work:  0.415 (Depositor)
  • R-Value Observed: 0.415 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50α = 90
b = 125.35β = 90
c = 312.06γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing
CNSrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-01-07
    Type: Initial release
  • Version 1.1: 2008-04-28
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-16
    Changes: Data collection, Database references, Refinement description
