1KBT

SOLUTION STRUCTURE OF CARDIOTOXIN IV, NMR, 12 STRUCTURES


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Submitted: 12

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Comparison of the hemolytic activity and solution structures of two snake venom cardiotoxin analogues which only differ in their N-terminal amino acid.

Jang, J.Y.Krishnaswamy, T.Kumar, S.Jayaraman, G.Yang, P.W.Yu, C.

(1997) Biochemistry 36: 14635-14641

  • DOI: https://doi.org/10.1021/bi971107a
  • Primary Citation of Related Structures:
    1KBS, 1KBT

  • PubMed Abstract:

    Cardiotoxin analogues IV (CTX IV) and II (CTX II) isolated from the venom of Taiwan Cobra (Naja naja atra) differ in their amino acid sequence by a single amino acid at the N-terminal end. Leucine at the N-terminal end in CTX II is replaced by arginine in CTX IV. CTX IV is an unique snake venom cardiotoxin as it is the only cardiotoxin isoform known so far which possesses a positively charged residue at the N-terminal amino acid. All other cardiotoxins have a hydrophobic amino acid (leucine or isoleucine) at their N-terminal end. The aim of the present study is to understand the effect(s) of the presence of a cationic residue on the structure and functional properties of cardiotoxin(s). Comparison of the hemolytic activities of CTX IV and CTX II shows that lytic activity of the former is at least twice as that shown by the latter. Comparison of the solution structures of CTX IV and CTX II using two-dimensional NMR spectroscopy and dynamical simulated annealing technique reveals that the backbone fold of both the toxin isoforms is almost similar. The secondary structural elements in these two cardiotoxin isoforms consist of long, triple-stranded, as well as short, double-stranded, antiparallel beta-sheets. Thermal denaturation experiments showed that the structure of CTX IV is more stable than that of CTX II. Critical analysis of the three-dimensional structures of CTX IV and CTX II reveals the presence of a "cationic" cluster comprising of positively charged residues on the concave side of the CTX IV molecule. Similar clusters consisting of positively charged residues are not found in CTX II. The differential erythrocyte lytic activities of these two cardiotoxins are attributed to the difference(s) in the distribution of the positively charged residues in their three-dimensional structures.


  • Organizational Affiliation

    Department of Chemistry, National Tsing Hua University, Hsinchu, Taiwan, ROC.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CTX IV60Naja atraMutation(s): 0
UniProt
Find proteins for P01443 (Naja atra)
Explore P01443
Go to UniProtKB:  P01443
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01443
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Submitted: 12

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-07-23
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-02-23
    Changes: Database references, Derived calculations, Other
  • Version 1.4: 2024-10-30
    Changes: Data collection, Structure summary
