1K2I

Crystal Structure of Gamma-Chymotrypsin in Complex with 7-Hydroxycoumarin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.200
  • R-Value Work: 0.180
  • R-Value Observed: 0.190

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted SN1Click on this verticalbar to view details

This is version 1.3 of the entry. See complete history


Literature

Crystal structure of gamma-chymotrypsin in complex with 7-hydroxycoumarin.

Ghani, U.Ng, K.K.Atta-ur-RahmanChoudhary, M.I.Ullah, N.James, M.N.

(2001) J Mol Biol 314: 519-525

  • DOI: https://doi.org/10.1006/jmbi.2001.5148
  • Primary Citation of Related Structures:
    1K2I

  • PubMed Abstract:

    The 1.8 A crystal structure of 7-hydroxycoumarin (7-HC) bound to chymotrypsin reveals that this inhibitor forms a planar cinnamate acyl-enzyme complex. The phenyl ring of the bound inhibitor forms numerous van der Waals contacts in the S1 pocket of the enzyme, with the p-hydroxyl group donating a hydrogen bond to the main-chain oxygen atom of Ser217, and the o-hydroxyl group forming a water-mediated hydrogen bond with the carbonyl oxygen of Val227. The structure of the acyl-enzyme complex suggests that the mechanism of inhibition of 7-HC involves nucleophilic attack by the Ser195 O(gamma) atom on the carbonyl carbon atom of the inhibitor, accompanied by the breaking of the 2-pyrone ring of the inhibitor, and leading to the formation of a cinnamate acyl-enzyme derivative via a tetrahedral transition state. Comparisons with structures of photoreversible cinnamates bound to chymotrypsin reveal that although 7-HC interacts with the enzyme in a similar fashion, the binding of 7-HC to chymotrypsin takes place in a productive conformation in contrast to the photoreversible cinnamates. In summary, the 7-HC-chymotrypsin complex provides basic insight into the inhibition of chymotrypsin by natural coumarins and provides a structural basis for the design of more potent mechanism-based inhibitors against a wide range of biologically important chymotrypsin-like enzymes.


  • Organizational Affiliation

    International Centre for Chemical Sciences, H. E. J. Research Institute of Chemistry, University of Karachi, Karachi, 75270, Pakistan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CHYMOTRYPSINOGEN AA [auth 1]245Bos taurusMutation(s): 0
EC: 3.4.21.1
UniProt
Find proteins for P00766 (Bos taurus)
Explore P00766
Go to UniProtKB:  P00766
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00766
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Binding Affinity Annotations
IDSourceBinding Affinity
SN1 PDBBind:  1K2I IC50: 7.80e+5 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.200
  • R-Value Work: 0.180
  • R-Value Observed: 0.190
  • Space Group: P 42 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.852α = 90
b = 69.852β = 90
c = 97.38γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
CNSrefinement
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted SN1Click on this verticalbar to view details

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-12-05
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2023-08-16
    Changes: Data collection, Database references, Derived calculations, Refinement description
