1HUK | pdb_00001huk

REFINED STRUCTURE OF YEAST INORGANIC PYROPHOSPHATASE AND ITS K61R MUTANT

PDB DOI: https://doi.org/10.2210/pdb1HUK/pdb

Classification: HYDROLASE
Organism(s): Saccharomyces cerevisiae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 1997-12-26 Released: 1998-04-08
Deposition Author(s): Swaminathan, K., Cooperman, B.S., Lahti, R., Voet, D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.288 (Depositor), 0.271 (DCC)
R-Value Work:
0.193 (Depositor), 0.184 (DCC)
R-Value Observed:
0.193 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1HUK

This is version 1.4 of the entry. See complete history.

Literature

Refined Structure of Yeast Inorganic Pyrophosphatase and its K61R Mutant

Swaminathan, K., Cooperman, B.S., Lahti, R., Voet, D.

To be published.

Macromolecule Content

Total Structure Weight: 63.61 kDa
Atom Count: 4,805
Modeled Residue Count: 562
Deposited Residue Count: 562
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
INORGANIC PYROPHOSPHATASE	A, B	281	Saccharomyces cerevisiae	Mutation(s): 0 EC: 3.6.1.1
UniProt
Find proteins for P00817 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P00817 Go to UniProtKB: P00817
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P00817
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.288 (Depositor), 0.271 (DCC)
R-Value Work: 0.193 (Depositor), 0.184 (DCC)
R-Value Observed: 0.193 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.09	α = 90
b = 93.06	β = 99.62
c = 51.58	γ = 90

Software Package:

Software Name	Purpose
X-PLOR	model building
X-PLOR	refinement
DENZO	data reduction
X-PLOR	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 1998-04-08

Deposition Author(s):

Swaminathan, K.

Cooperman, B.S.

Revision History (Full details and data files)

Version 1.0: 1998-04-08
Type: Initial release
Version 1.1: 2008-03-03
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2023-08-09
Changes: Database references, Derived calculations, Other, Refinement description
Version 1.4: 2024-05-22
Changes: Data collection
