1H74 | pdb_00001h74

CRYSTAL STRUCTURE OF HOMOSERINE KINASE COMPLEXED WITH ILE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.238 (Depositor), 0.303 (DCC)
  • R-Value Work:
    0.210 (Depositor), 0.283 (DCC)
  • R-Value Observed:
    0.210 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1H74

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Structural Basis for the Catalysis and Substrate Specificity of Homoserine Kinase

Krishna, S.S.Zhou, T.Daugherty, M.Osterman, A.L.Zhang, H.

(2001) Biochemistry 40: 10810

  • DOI: https://doi.org/10.1021/bi010851z
  • Primary Citation Related Structures:
    1H72, 1H73, 1H74

  • PubMed Abstract:

    Homoserine kinase (HSK), the fourth enzyme in the aspartate pathway of amino acid biosynthesis, catalyzes the phosphorylation of L-homoserine (Hse) to L-homoserine phosphate, an intermediate in the production of L-threonine, L-isoleucine, and in higher plants, L-methionine. The high-resolution structures of Methanococcus jannaschii HSK ternary complexes with its amino acid substrate and ATP analogues have been determined by X-ray crystallography. These structures reveal the structural determinants of the tight and highly specific binding of Hse, which is coupled with local conformational changes that enforce the sequestration of the substrate. The delta-hydroxyl group of bound Hse is only 3.4 A away from the gamma-phosphate of the bound nucleotide, poised for the in-line attack at the gamma-phosphorus. The bound nucleotides are flexible at the triphosphate tail. Nevertheless, a Mg(2+) was located in one of the complexes that binds between the beta- and gamma-phosphates of the nucleotide with good ligand geometry and is coordinated by the side chain of Glu130. No strong nucleophile (base) can be located near the phosphoryl acceptor hydroxyl group. Therefore, we propose that the catalytic mechanism of HSK does not involve a catalytic base for activating the phosphoryl acceptor hydroxyl but instead is mediated via a transition state stabilization mechanism.


  • Organizational Affiliation
    • Department of Biochemistry, University of Texas Southwestern Medical Center, 5323 Harry Hines Boulevard, Dallas, Texas 75390-9038, USA.

Macromolecule Content

  • Total Structure Weight: 131.65 kDa
  • Atom Count: 9,718
  • Modeled Residue Count: 1,184
  • Deposited Residue Count: 1,184
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
HOMOSERINE KINASE
A, B, C, D
296Methanocaldococcus jannaschiiMutation(s): 0
EC: 2.7.1.39
UniProt
Find proteins for Q58504 (Methanocaldococcus jannaschii (strain ATCC 43067 / DSM 2661 / JAL-1 / JCM 10045 / NBRC 100440))
Explore Q58504
Go to UniProtKB:  Q58504
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ58504
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
AGS

Query on AGS



Download:Ideal Coordinates CCD File
H [auth B],
M [auth D]
PHOSPHOTHIOPHOSPHORIC ACID-ADENYLATE ESTER
C10 H16 N5 O12 P3 S
NLTUCYMLOPLUHL-KQYNXXCUSA-N
ADP

Query on ADP



Download:Ideal Coordinates CCD File
F [auth A],
K [auth C]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
ILE

Query on ILE



Download:Ideal Coordinates CCD File
E [auth A],
G [auth B],
J [auth C],
L [auth D]
ISOLEUCINE
C6 H13 N O2
AGPKZVBTJJNPAG-WHFBIAKZSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
I [auth B]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.238 (Depositor), 0.303 (DCC)
  • R-Value Work:  0.210 (Depositor), 0.283 (DCC)
  • R-Value Observed: 0.210 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 61.993α = 90
b = 128.721β = 105.57
c = 109.423γ = 90
Software Package:
Software NamePurpose
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-11-28
    Type: Initial release
  • Version 1.1: 2013-01-30
    Changes: Atomic model, Database references, Derived calculations, Non-polymer description, Other, Version format compliance
  • Version 1.2: 2019-05-22
    Changes: Data collection, Other, Refinement description
  • Version 1.3: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
