1EWQ | pdb_00001ewq

CRYSTAL STRUCTURE TAQ MUTS COMPLEXED WITH A HETERODUPLEX DNA AT 2.2 A RESOLUTION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.259 (Depositor)
  • R-Value Work:
    0.227 (Depositor)
  • R-Value Observed:
    0.227 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1EWQ

This is version 1.5 of the entry. See complete history

Literature

Crystal structures of mismatch repair protein MutS and its complex with a substrate DNA.

Obmolova, G.Ban, C.Hsieh, P.Yang, W.

(2000) Nature 407: 703-710

  • DOI: https://doi.org/10.1038/35037509
  • Primary Citation Related Structures:
    1EWQ, 1EWR

  • PubMed Abstract:

    DNA mismatch repair is critical for increasing replication fidelity in organisms ranging from bacteria to humans. MutS protein, a member of the ABC ATPase superfamily, recognizes mispaired and unpaired bases in duplex DNA and initiates mismatch repair. Mutations in human MutS genes cause a predisposition to hereditary nonpolyposis colorectal cancer as well as sporadic tumours. Here we report the crystal structures of a MutS protein and a complex of MutS with a heteroduplex DNA containing an unpaired base. The structures reveal the general architecture of members of the MutS family, an induced-fit mechanism of recognition between four domains of a MutS dimer and a heteroduplex kinked at the mismatch, a composite ATPase active site composed of residues from both MutS subunits, and a transmitter region connecting the mismatch-binding and ATPase domains. The crystal structures also provide a molecular framework for understanding hereditary nonpolyposis colorectal cancer mutations and for postulating testable roles of MutS.


  • Organizational Affiliation
    • Genetics and Biochemistry Branch, National Institute of Diabetes and Digestive and Kidney Diseases, National Institutes of Health, Bethesda, Maryland 20892, USA.

Macromolecule Content

  • Total Structure Weight: 187.44 kDa
  • Atom Count: 13,724
  • Modeled Residue Count: 1,553
  • Deposited Residue Count: 1,575
  • Unique protein chains: 1
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA MISMATCH REPAIR PROTEIN MUTSC [auth A],
D [auth B]
765Thermus aquaticusMutation(s): 13
UniProt
Find proteins for Q56215 (Thermus aquaticus)
Explore Q56215
Go to UniProtKB:  Q56215
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ56215
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*CP*GP*AP*CP*GP*CP*TP*AP*GP*CP*GP*TP*GP*CP*GP*GP*CP*TP*CP*GP*TP*C)-3')A [auth C]23N/A
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*GP*AP*CP*GP*AP*GP*CP*CP*GP*CP*CP*GP*CP*TP*AP*GP*CP*GP*TP*CP*G)-3')B [auth D]22N/A
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4

Query on SO4



Download:Ideal Coordinates CCD File
E [auth A],
F [auth A],
H [auth B],
I [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
EDO

Query on EDO



Download:Ideal Coordinates CCD File
G [auth A]
J [auth B]
K [auth B]
L [auth B]
M [auth B]
G [auth A],
J [auth B],
K [auth B],
L [auth B],
M [auth B],
N [auth B],
O [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
C [auth A],
D [auth B]
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.259 (Depositor)
  • R-Value Work:  0.227 (Depositor)
  • R-Value Observed: 0.227 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 103.167α = 90
b = 114.216β = 90
c = 160.792γ = 90
Software Package:
Software NamePurpose
SOLVEphasing
CNSrefinement
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2000-10-23
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-04
    Changes: Refinement description
  • Version 1.4: 2021-11-03
    Changes: Database references, Derived calculations
  • Version 1.5: 2024-11-20
    Changes: Data collection, Structure summary
