1AQD | pdb_00001aqd

HLA-DR1 (DRA, DRB1 0101) HUMAN CLASS II HISTOCOMPATIBILITY PROTEIN (EXTRACELLULAR DOMAIN) COMPLEXED WITH ENDOGENOUS PEPTIDE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.45 Å
  • R-Value Free:
    0.279 (Depositor), 0.264 (DCC)
  • R-Value Work:
    0.216 (Depositor), 0.206 (DCC)
  • R-Value Observed:
    0.216 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1AQD

This is version 1.4 of the entry. See complete history

Literature

The class II MHC protein HLA-DR1 in complex with an endogenous peptide: implications for the structural basis of the specificity of peptide binding.

Murthy, V.L.Stern, L.J.

(1997) Structure 5: 1385-1396

  • DOI: https://doi.org/10.1016/s0969-2126(97)00288-8
  • Primary Citation Related Structures:
    1AQD

  • PubMed Abstract:

    Class II major histocompatibility complex (MHC) proteins are cell surface glycoproteins that bind peptides and present them to T cells as part of the mechanism for detecting and responding to foreign material in the body. The peptide-binding activity exhibits allele-specific preferences for particular sidechains at some positions, although the structural basis of these preferences is not understood in detail. We have determined the 2.45 A crystal structure of the human class II MHC protein HLA-DR1 in complex with the tight binding endogenous peptide A2 (103-117) in order to discover peptide-MHC interactions that are important in determining the binding motif and to investigate conformational constraints on the bound peptide. The bound peptide adopts a polyproline II-like conformation and places several sidechains within pockets in the binding site. Bound water molecules mediate MHC-peptide contacts at several sites. A tryptophan residue from the beta 2 'lower' domain of HLA-DR1 was found to project into a pocket underneath the peptide-binding domain and may be important in modulating interdomain interactions in MHC proteins. The peptide-binding motif of HLA-DR1 includes an aromatic residue at position +1, an arginine residue at position +2, and a small residue at position +6 (where the numbering refers to the normal MHC class II convention); these preferences can be understood in light of interactions observed in the peptide-MHC complex. Comparison of the structure with that of another MHC-peptide complex shows that completely different peptide sequences bind in essentially the same conformation and are accommodated with only minimal rearrangement of HLA-DR1 residues. Small conformational differences that are observed appear to be important in interactions with other proteins.


  • Organizational Affiliation
    • Johns Hopkins University School of Medicine, Baltimore, MD 21210, USA.

Macromolecule Content

  • Total Structure Weight: 188.15 kDa
  • Atom Count: 12,638
  • Modeled Residue Count: 1,514
  • Deposited Residue Count: 1,620
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
HLA-DR1 CLASS II HISTOCOMPATIBILITY PROTEIN
A, D, G, J
192Homo sapiensMutation(s): 0
Gene Names: DRA*0101DRB1*0101
UniProt & NIH Common Fund Data Resources
Find proteins for P01903 (Homo sapiens)
Explore P01903
Go to UniProtKB:  P01903
PHAROS:  P01903
GTEx:  ENSG00000204287
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01903
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
HLA-DR1 CLASS II HISTOCOMPATIBILITY PROTEIN
B, E, H, K
198Homo sapiensMutation(s): 0
Gene Names: DRA*0101DRB1*0101
UniProt & NIH Common Fund Data Resources
Find proteins for P01911 (Homo sapiens)
Explore P01911
Go to UniProtKB:  P01911
PHAROS:  P01911
GTEx:  ENSG00000196126
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01911
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
HLA-A2
C, F, I, L
15Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P04439 (Homo sapiens)
Explore P04439
Go to UniProtKB:  P04439
PHAROS:  P04439
GTEx:  ENSG00000206503
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04439
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.45 Å
  • R-Value Free:  0.279 (Depositor), 0.264 (DCC)
  • R-Value Work:  0.216 (Depositor), 0.206 (DCC)
  • R-Value Observed: 0.216 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 134.514α = 90
b = 134.32β = 104.82
c = 131.232γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1998-01-28
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-02
    Changes: Database references, Refinement description
  • Version 1.4: 2024-11-20
    Changes: Data collection, Structure summary
