13LN | pdb_000013ln

Structure of human TRPV3-Q580P Olmsted syndrome mutant in the inactivated state

  • Classification: MEMBRANE PROTEIN
  • Organism(s): Homo sapiens, Aequorea victoria
  • Expression System: Homo sapiens
  • Mutation(s): Yes

  • Deposited: 2026-05-13 Released: 2026-07-01
  • Deposition Author(s): Purohit, R., Khau, J., Nadezhdin, K.D., Sobolevsky, A.I.
  • Funding Organization(s): National Institutes of Health/National Institute of Arthritis and Musculoskeletal and Skin Diseases (NIH/NIAMS), National Institutes of Health/National Cancer Institute (NIH/NCI), National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.02 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 13LN

This is version 1.0 of the entry. See complete history

Literature

Structural diversity of heat-sensing channel TRPV3 with Olmsted syndrome mutations.

Khau, J.Purohit, R.Nadezhdin, K.D.Talyzina, I.A.Sobolevsky, A.I.

(2026) Nat Commun

  • DOI: https://doi.org/10.1038/s41467-026-74687-5
  • Primary Citation Related Structures:
    13LJ, 13LK, 13LM, 13LN, 13LO, 13LP, 13LQ, 13LR, 13LS, 13LT, 13LU, 9PJ5, 9PJ6

  • PubMed Abstract:

    Mutations in TRPV3, a temperature-sensitive ion channel critical for skin physiology, cause severe genodermatosis called Olmsted syndrome (OS). Here we integrate single-channel recordings and cryo-EM to characterize five OS mutants. All exhibit reduced temperature sensitivity in the temperature range relevant to normal skin physiology and disrupt structural elements stabilizing non-conducting states, including vanilloid lipid coordination and S4-S5 linker-TRP helix contacts. Despite shared gain-of-function phenotype, the mutations cause different distributions of the TRPV3 closed, open, and inactivated states. One mutation expands the conformational ensemble with noncanonical two-fold-symmetrical states featuring dramatic domain swapping. Our findings highlight conserved TRP channel gating mechanisms and suggest that OS mutations alter TRPV3 function by triggering the conformational wave that mediates gating in wild-type channels. These insights establish a framework to decode genotype-structure-function relationships in TRP channelopathies and guide future therapeutic strategies.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY, USA.

Macromolecule Content

  • Total Structure Weight: 504.82 kDa
  • Atom Count: 22,147
  • Modeled Residue Count: 2,504
  • Deposited Residue Count: 4,208
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Isoform 2 of Transient receptor potential cation channel subfamily V member 3,Green fluorescent protein
A, B, C, D
1,052Homo sapiensAequorea victoria
This entity is chimeric
Mutation(s): 1
Gene Names: TRPV3GFP
UniProt & NIH Common Fund Data Resources
Find proteins for Q8NET8 (Homo sapiens)
Go to UniProtKB:  Q8NET8
PHAROS:  Q8NET8
GTEx:  ENSG00000167723
Find proteins for P42212 (Aequorea victoria)
Explore P42212
Go to UniProtKB:  P42212
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsQ8NET8-2P42212
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
POV

Query on POV



Download:Ideal Coordinates CCD File
AA [auth C]
BA [auth C]
CA [auth C]
DA [auth C]
E [auth A]
AA [auth C],
BA [auth C],
CA [auth C],
DA [auth C],
E [auth A],
EA [auth C],
F [auth A],
FA [auth C],
G [auth A],
GA [auth D],
H [auth A],
HA [auth D],
I [auth A],
IA [auth D],
J [auth A],
JA [auth D],
K [auth A],
KA [auth D],
L [auth A],
LA [auth D],
M [auth A],
MA [auth D],
Q [auth B],
R [auth B],
S [auth B],
T [auth B],
U [auth B],
V [auth B],
W [auth B],
X [auth C],
Y [auth C],
Z [auth C]
(2S)-3-(hexadecanoyloxy)-2-[(9Z)-octadec-9-enoyloxy]propyl 2-(trimethylammonio)ethyl phosphate
C42 H82 N O8 P
WTJKGGKOPKCXLL-PFDVCBLKSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
N [auth A],
O [auth A],
P [auth A]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.02 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Arthritis and Musculoskeletal and Skin Diseases (NIH/NIAMS)United StatesR01 AR078814
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesR01 CA206573
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)United StatesR01 NS083660
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)United StatesR01 NS107253

Revision History  (Full details and data files)

  • Version 1.0: 2026-07-01
    Type: Initial release
